User Guide
5.8 In-Band Management Usage
The following are requirements to use the in-band connections:
• The "openflex-api" application must be installed and running on the Host Initiator server
• At least one MI Device has been successfully connected
Note:
After the MI Device connection(s) are established, the OpenFlex API requires a "GET /
Query/" for the API to discover the In-Band Path to communicate to the MI Device(s). This is
also true if there are MI Device changes or if the MI Device(s) disconnect and then reconnect.
In-Band Management Path Connectivity
•
Method #1 - API via In-Band Network Connection (using a Browser) (page 204)
to connect to the In-Band management port via "Host" OpenFlex API to the Data24 to manage the
enclosure over the AIC-C Target Port
•
Method #2 - API via In-band Network Connection (using CURL) (page 208)
to the In-Band management port via "Host" OpenFlex API to the Data24 to manage the enclosure over
the AIC-C Target Port
•
Method #3 - GUI via In-band Network Connection (page 218)
Browser via the "Host" OpenFlex API to the Data24 to manage the enclosure over the AIC-C Target Port
5.8.1 In-Band Management Path Connectivity
Method #1 - API via In-Band Network Connection (using a Browser)
Determine the API path to the Data24 using the Host Initiator OpenFlex API "doorbell"
API Command: "GET /Query/"
Result: Target URI Path List showing the Compute Proxy plus the 1 or 2 "in-band path URIs"
EXAMPLE USAGE
Send this URI via the Browser Address Line:
{
"Self": "http://10.202.238.146:80/Query/",
"SystemQuery": "http://10.202.238.146:80/System/Query/",
"InformationStructure": {
"Self": "http://10.202.238.146:80/Query/InformationStructure/",
"AuthenticationType": {
"ID": 0,
"Name": "Basic"
},
"HTTPPort": 80,
"HTTPSPort": 443,
"LogLevel": "info",
"MaximumThreads": 6,
"Name": "OpenFlex API",
"OwningOrganization": "Copyright 2023 Western Digital Corporation or its
affiliates. All rights reserved.",
"Status": "Released",
:
5.8 In-Band Management Usage
: Using the Data24 Device Page GUI via
http://10.202.238.146/Query/
5. Configuration
: Using a Browser
: Using "CURL" to connect
204
