The firmware is downloaded.
Use
Step 4 :
fw-activate
nvme fw-activate /dev/nvme3 -s 3 -a 3
The firmware is successfully committed and the SSDs will reset.
Step 5 : Confirm the firmware version that is now loaded on the drive use
nvme fw-log /dev/nvme3
The NVMe device firmware information is displayed.
Firmware Log for device:nvme3
afi
frs1 : 0x3330303930313252 (R2109003)
frs2 : 0x3330303930313252 (R2109003)
frs3 : 0x3030323930323252 (R2209200)
frs4 : 0x3330303930313252 (R2109003)
Step 6 : Verify that the expected firmware slot is active under 'afi' by confirming both the first and second
afi values are the same. This ensures that the firmware stays persistent after drive reboot/reset.
The API Firmware data does not update until the drive or the enclosure is rebooted.
4.4 Platform Details Pullout Tab
There is a small plastic tab that can be pulled out to show the vital system details such as the SKU number
and single Top Level Serial Number. This is the only location for the product SN. The pullout tab is located
on the front of the platform in the location shown in the following image.
to activate firmware and commit to install the loaded firmware version.
When updating drive firmware use nvme fw-activate action 3.
Note:
: 0x33
4. Management

4.4 Platform Details Pullout Tab

and review the ouput.
fw-log
