User Guide
"Health": [{
"ID": 5,
"Name": "OK"
}]
},
"Associations": {
"Adapters": ["3"],
"Ports": ["70_b3_d5_76_8e_ca_192_168_0_53_24"]
},
"AddressOrigin": {
"ID": 65536,
"Name": "DHCPv4"
},
"CablePresent": true,
"IPv4Address": "192.168.0.53/24",
"IPv4Gateway": "192.168.0.1",
"LinkStatus": true,
"MACAddress": "70:b3:d5:76:8e:ca",
"NetworkType": {
"ID": 8,
"Name": "IPv4 Network"
},
"MTUBytes": 2200,
"Speed": 100000000000,
"Adapters": "http://10.202.237.225:80/Storage/Devices/openflex-data24-
usalp03020qb0007/Adapters/?Ports=70_b3_d5_76_8e_ca_192_168_0_53_24"
}]
}
Determine the Data24 Host Adapter connection IP Address for Controller 2 (IOM-B) via out-of-band
connection (IOM-B AIC-C = Adapter 6)
API Command: "GET /Storage/Devices/{id}/Ports/?Adapters=6"
Result: Target Add-in-Card IP Address = 192.168.1.53
EXAMPLE USAGE
$ curl -u admin:admin http://10.202.237.225/Storage/Devices/openflex-data24-
usalp03020qb0007/Ports/?Adapters=6
{
"Self": "http://10.202.237.225:80/Storage/Devices/openflex-data24-usalp03020qb0007/
Ports/",
"Members": [{
"Self": "http://10.202.237.225:80/Storage/Devices/openflex-data24-usalp03020qb0007/
Ports/70_b3_d5_76_8e_2e_192_168_1_53_24/",
"ID": "70_b3_d5_76_8e_2e_192_168_1_53_24",
"Status": {
"State": {
"ID": 16,
"Name": "In service"
},
"Health": [{
"ID": 5,
"Name": "OK"
}]
},
"Associations": {
"Adapters": ["6"],
"Ports": ["70_b3_d5_76_8e_2e_192_168_1_53_24"]
:
5. Configuration
5.7 In-Band Management Setup
197
