User Guide
The Update Port window appears, showing the Address Type, IP, MTUBytes step:
Figure 195: Add-in Card Device Update Port Window
Edit the port information for the device and click the Next button:
Step 8 :
The Confirmation step appears.
Step 9 : Select the Please Confirm checkbox to confirm the edits:
The port will be updated and reset, resulting in dropping any active
Note:
connections.
Attention: The MTU Bytes for the IOM 100Gbs data ports (AIC) default to a value
of 5000. This is recommended setting for the component, but it can be changed
with the range of 1500 and 5000.
4. Management
4.2 Open Composable GUI
140
