  • Page 1 EcoDesign Disclosures Ultrastar® Data60 Regulatory Model: H4060-J 1ET2154 Version 1.0 February 2020...

  • Page 2: Table Of Contents

    EcoDesign Disclosures Table of Contents Table of Contents Notices......................................ii Chapter 1. EU EcoDesign Disclosures............................1 EcoDesign Overview................................. 2 Ultrastar Data60 EcoDesign Specifications..........................2 Instant Secure Erase / Secure Erase............................2 Ultrastar Data60 Disassembly..............................4...

  • Page 3: Notices

    Per Western Digital Terms and Conditions of Sale, the user of Western Digital products in life support applications assumes all risk of such use and indemnifies Western Digital against all damages.

  • Page 4: Chapter 1. Eu Ecodesign Disclosures

    Western Digital EU EcoDesign Disclosures This document provides information and instructions related to the Ultrastar Data60 's disclosures for the EU's ecodesign requirements. In This Chapter: - EcoDesign Overview........2 - Ultrastar Data60 EcoDesign Specifications...........2 - Instant Secure Erase / Secure Erase.... 2...

  • Page 5: Ecodesign Overview

    1. EU EcoDesign Disclosures EcoDesign Disclosures 1.1 EcoDesign Overview 1.1   EcoDesign Overview This document provides information about the Ultrastar Data60 related to its manufacturing and operation, and instructions for secure data deletion and disassembly. 1.2   Ultrastar Data60 EcoDesign Specifications Product Type...
  • Page 6 /documents.westerndigital.com/content/dam/doc-library/en_us/assets/public/western-digital/ collateral/tech-brief/tech-brief-instant-secure-erase..ISE / SE Overview Instant Secure Erase (ISE) is Western Digital’s implementation of the industry standard T10 (SAS)/T13 (SATA) command, allowing users to instantly erase both user-accesible data and hidden user data from sanitize Western Digital drives.

  • Page 7: Ultrastar Data60 Disassembly

    Cryptographic Erase: All user data shall be erased cryptographically. This is accomplished by deleting the encryption key. 1.4   Ultrastar Data60 Disassembly This task provides instructions for disassembling an Ultrastar Data60 to meet the EU's ecodesign requirements.
  • Page 8 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Table 1: Procedure Requirements Time Required Tools # of People Required Required T7, T8, T10 Torx Screwdrivers  * 2 hours #2 Phillips Screwdriver Opening the CMA(s) Step 1 : Place the CMA(s) into service position.
  • Page 9 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 2 : Disconnect the Enclosure from power. a. Locate the redundant PSUs at the rear of the enclosure. b. Detach the cable retention clip from both power cords. Figure 3: Cable Retention Mechanism c.
  • Page 10 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 4: Open Baskets b. Remove one cable at a time from the arm, making sure not to put too much strain on the arm. Removing the CMA(s) Step 6 : Remove the CMA(s).
  • Page 11 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly a. Locate the crossbar thumbscrew that secures the crossbar to the CMA mounting brackets and unscrew it. Figure 6: Unscrew Thumbscrew b. Swing the crossbar away from the enclosure. Figure 7: Crossbar Swinging Out c.
  • Page 12 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 8: Uninstalling PSU b. Pull the PSU straight out with even pressure. Uninstalling the Rear Fans Step 9 : To unlatch the rear fan from the fan housing, use one hand to press the clip at the top and...
  • Page 13 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 9: Uninstalling the Rear Fan Extending the Enclosure Step 10 : Grasp both handles at the front of the enclosure and pull with even pressure to extend the chassis out of the rack until it is stopped by the safety latches. The safety latches will prevent the enclosure from coming out of the rack completely and the cover will remain in the rack attached to the rear alignment brackets.
  • Page 14 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 10: Chassis Handle Operation Removing the Drives Step 11 : Follow these steps to remove a Drive Assembly. a. Find the latch release mechanism on the Drive Assembly being removed.
  • Page 15 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 12: Removing Drive Assembly Step 12 : Repeat these steps to remove all the drive assemblies from the enclosure. Removing the IOMs Step 13 : Uninstall the IOM(s). a. Locate the latch release on the IOM and press it in the direction shown in the following image.
  • Page 16 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 14: Removing IOM Step 14 : Repeat these steps to remove the remaining IOM from the enclosure. Disassembling the IOMs Step 15 : Lay one of the IOMs on its side.
  • Page 17 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 18 : Using a T10 Torx screwdriver, remove the six (6) M3 4mm pan-head screws securing the circuit board to the other side-panel: Step 19 : Pull the circuit board upward to remove it from the IOM:...
  • Page 18 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 20 : If applicable, repeat these steps to remove the circuit board from the other IOM. Removing the IOM Fan Step 21 : Remove the IOM Fan. a. With one hand, grasp around the center square of the fan housing as shown in the following image.
  • Page 19 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 19: Removing IOM Fan Releasing the Chassis Cover From the Rack Step 22 : Release the safety latch on the inner rails on each side of the chassis as shown in the following image.
  • Page 20 Warning: The handles on the front of the chassis are not intended to be used to support the weight of the Ultrastar Data60 . Lifting the unit by the chassis handles or trying to support the unit on the handles can cause them to fail.
  • Page 21 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 22: Safety Latch Release d. Depress the latch release lever for the safety latches on the rail and push the chassis very slightly forward. The chassis is now unsecured from the rack.
  • Page 22 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 23: Remove Inner Rail b. Locate and unlatch the springlock on the side of the inner rail. Figure 24: Inner Rail Spring Latch c. Slide the inner rail toward the front of the enclosure to unlock it from the pegs that secure it to the sidewall and pull it free.
  • Page 23 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 25: Uninstalling the Cable Tray Removing the Chassis Cover from the Enclosure Step 29 : Slide the chassis cover toward the rear of the enclosure. Then lift it up to remove it from the...
  • Page 24 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Removing the PDB Cover The PDB cover is shown in red in the following image:...
  • Page 25 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 27: PDB Cover Location Step 30 : Use a T7 Torx screwdriver to remove the three (3) M3 6mm screws securing the PDB cover to the left and right drive housings. Then pull up on the PDB cover to remove it from the chassis:...
  • Page 26 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Removing the Plenum Covers The plenum covers are shown in red in the following image:...
  • Page 27 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 29: Plenum Covers Location Step 31 : Use a T7 Torx screwdriver to remove the four (4) M3 6mm screws securing the plenum covers to the left and right drive housings:...
  • Page 28 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 32 : Remove the four (4) M3 7mm screws securing the plenum covers to the fan housing:...
  • Page 29 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 33 : Pull up on the plenum covers to remove them from the chassis:...
  • Page 30 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Removing the Fan Housing Assembly The fan housing assembly is shown in red in the following image:...
  • Page 31 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 33: Fan Housing Assembly Location Step 34 : Use a T7 Torx screwdriver to remove the twelve (12) M3 6mm screws securing the back of the fan housing assembly to the back of the chassis. The screws are shown in red in the following image: Figure 34: Fan Housing, As Viewed from the Rear Step 35 : Use a T7 Torx screwdriver to remove the twelve (12) M3 6mm screws securing the sides of the fan...
  • Page 32 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 36 : Pull the fan housing assembly away from the chassis, just far enough to unplug the fan cable connectors from their receptacles on the baseboard. The fan cables, connectors, and...
  • Page 33 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 36: Fan Cable Connectors, As Viewed from the Top-Rear Step 37 : Remove the fan housing assembly from the chassis:...
  • Page 34 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Removing the PDB Bus-Bar Screws The PDB bus-bar and screws are shown in red in the following image:...
  • Page 35 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 38: PDB Bus-Bar Screws, As Viewed from the Top-Front Step 38 : Use a T8 Torx screwdriver to remove the four (4) M3 6mm screws securing the PDB to the...
  • Page 36 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Removing the IO Housing The IO housing is shown in red in the following image:...
  • Page 37 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 40: IO Housing Location Step 39 : Use a T7 Torx screwdriver to remove the fourteen (14) M3 6mm screws securing the IO housing to the drive housings and chassis. Then pull the IO housing up to remove it from the chassis:...
  • Page 38 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Removing the PDB from the IO Housing Step 40 : Lay the IO housing on its side. Step 41 : Use a T7 Torx screwdriver to remove the eighteen (18) M3 6mm screws securing the right side...
  • Page 39 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 42 : Use a T7 Torx screwdriver to remove the three (3) M3 6mm screws securing the PDB to the left side panel of the IO housing:...
  • Page 40 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 43 : Lift the PDB to remove it from the IO housing:...
  • Page 41 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Removing the Drive Housings The right drive housing is shown in red in the following image.
  • Page 42 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 45: Right Drive Housing, As Viewed from the Right-Rear-Top Step 44 : At the front of the chassis, use a T7 Torx screwdriver to remove the two (2) M3 7mm screws...
  • Page 43 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 46: Right-Front Inside Corner, As Viewed from the Right-Rear-Top Step 45 : At the front of the chassis, use a T7 Torx screwdriver to remove the four (4) M3 6mm screws...
  • Page 44 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 47: Right-Front Inside Corner, As Viewed from the Left-Rear-Top Step 46 : Inside the drive bays of the right drive housing, use a T7 Torx screwdriver to remove the four (4)
  • Page 45 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 48: Right Drive Bays, As Viewed from the Right-Front-Top Step 47 : On the side of the chassis, use a T8 Torx screwdriver to remove the two (2) K30 10mm screws...
  • Page 46 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 49: Right-Front Outside Corner, As Viewed from the Right-Rear-Bottom Step 48 : On the side of the chassis, use a T7 Torx screwdriver to remove the twelve (12) M3 6mm screws...
  • Page 47 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 50: Right-Front Corner, As Viewed from the Right-Front-Top Step 49 : Pull up on the right drive housing to remove it from the chassis:...
  • Page 48 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 50 : Repeat these steps to remove the left drive housing. Removing the HDD Limiters The HDD limiters are shown in red in the following image.
  • Page 49 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 52: HDD Limiters Location The bottom side of each limiter has twelve (12) clips that hold it to the baseboard; these clips must be disengaged from the baseboard in order to remove the limiter:...
  • Page 50 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 53: HDD Limiter, Bottom Side Clips Step 51 : Use your fingers—or a flat object (flat-head screwdriver, etc.)—to pry up the 10 HDD limiters at their clip locations, and remove the limiters from the baseboard:...
  • Page 51 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Removing the Baseboards The baseboards are shown in red in the following image:...
  • Page 52 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Step 52 : Use a T7 Torx screwdriver to remove the twelve (12) M3 6mm screws securing the smaller, front baseboard to the chassis. The screws are shown in red in the following image:...
  • Page 53 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 56: Enclosure Front, As Viewed from the Front-Top Step 53 : Pull up to remove the smaller, front baseboard from the chassis:...
  • Page 54 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 57: Front Baseboard, As Viewed from the Right-Rear-Top Step 54 : Use a T7 Torx screwdriver to remove the thirteen (12) M3 6mm screws securing the larger, rear baseboard to the chassis. The screws are shown in red in the following image:...
  • Page 55 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 58: Enclosure Rear, As Viewed from the Front-Top Step 55 : Pull up to remove the larger, rear baseboard from the chassis:...
  • Page 56 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly Figure 59: Rear Baseboard, As Viewed from the Right-Rear-Top...
  • Page 57 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Ultrastar Data60 Disassembly The disassembly is now complete.
