  • Page 1 EcoDesign Disclosures OpenFlex™ Data24 Regulatory Model: DCS0010 D018-000332-000 Doc. Version 04 September 2022...

  • Page 2: Table Of Contents

    EcoDesign Disclosures Table of Contents Table of Contents Revision History........................................ii Notices............................................iii Chapter 1. EU EcoDesign Disclosures................1 EcoDesign Overview....................................2 OpenFlex™ Data24 EcoDesign Specifications........................2 Instant Secure Erase / Secure Erase............................3 OpenFlex™ Data24 Disassembly..............................4 IO Module (IOM) Disassembly................................33...

  • Page 3: Revision History

    Instant Secure Erase / Secure Erase (page 3) January 2022 section to include more information on NVMe Sanitize. Added information related to the Cable Management Arm February 2022 (CMA) Assembly during the disassembly procedures. September 2022 Rebranded document to new Western Digital design...

  • Page 4: Notices

    Per Western Digital Terms and Conditions of Sale, the user of Western Digital products in life support applications assumes all risk of such use and indemnifies Western Digital against all damages.

  • Page 5: Chapter 1. Eu Ecodesign Disclosures

    This document provides information and instructions related to the OpenFlex™ Data24's disclosures for the EU's ecodesign requirements. In This Chapter: - EcoDesign Overview....................... 2 - OpenFlex Data24 EcoDesign Specifications............2 - Instant Secure Erase / Secure Erase............... 3 - OpenFlex Data24 Disassembly.................. 4 - IO Module (IOM) Disassembly..................33...

  • Page 6: Ecodesign Overview

    This document provides information about the OpenFlex™ Data24 related to its manufacturing and operation, and instructions for secure data deletion and disassembly. 1.2  OpenFlex™ Data24 EcoDesign Specifications Online Data Storage Product Product Type Western Digital Manufacturer's Name Western Digital® Manufacturer's Registered Trade Name 5601 Great Oaks Parkway...

  • Page 7: Instant Secure Erase / Secure Erase

    Secure Erase (SE) features included with Western Digital drives. Data Erasure Options Western Digital provides several options for securely erasing data from its drives. The appropriate method depends upon many factors, including the following: • Erase Configuration (ISE or SE) •...

  • Page 8: Openflex™ Data24 Disassembly

    1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly If a drive is encrypted (TCG or FIPS), unlock the drive before executing any Note: sanitize commands. Note: In the following commands, replace the generic reference of with the specific <dev>...
  • Page 9 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 1: Move CMA Assembly into a Servicing State Step 3 : Disconnect the power and data cables from the enclosure. a. Unclip the retention strap as shown in the following image. Figure 2: Unclipping Cable Retention Strap (Generic PSU Shown) b.
  • Page 10 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 3: Disconnect Power Cables c. Disconnect the Ethernet Cable from the RJ45 Ethernet Management port. Figure 4: Disconnect RJ45 Ethernet Cables d. Disconnect the QSFP28 cables from all of the IOM ports. Figure 5: Disconnect QSFP28 Cables Step 4 : (Optional) Repeat the previous step to move the remaining arm into the servicing state.
  • Page 11 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 6: Drive Assembly Release Button and Handle Operation b. Pull down slightly on the release handle to unseat the Drive Assembly. Then pull the handle to remove the Drive Assembly from the enclosure: Figure 7: Drive Assembly Removal c.
  • Page 12 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 8: Supply Unit (PSU) Release Latch Operation b. Pull the Supply Unit (PSU) out of its slot: Figure 9: Supply Unit (PSU) Removal c. Repeat these steps to remove the remaining Supply Unit (PSU). Uninstall the IO Modules (IOMs).
  • Page 13 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 10: IO Module (IOM) Thumbscrew Operation b. Pull the release handle down until the IO Module (IOM) is unseated from its slot: Figure 11: IO Module (IOM) Release Handle Operation c.
  • Page 14 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 12: IO Module (IOM) Removal d. Repeat these steps to remove the remaining IO Module (IOM). Step 8 : Uninstall the Chassis from the rack mounted rails. a. From the front of the rack, using the T15 Torx screwdriver, loosen the two Torx captive screws that secure the Chassis to the rail.
  • Page 15 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly b. Carefully pull the Chassis out of the rack. The chassis will slide out of the rails until the locking tabs on the side of the chassis engage and stop the chassis from being pulled out further.
  • Page 16 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 15: Uninstall Chassis Remove the rear chassis cover. Step 9 : a. Using a T7 Torx screwdriver, remove the sixteen (16) screws securing the rear chassis cover: Figure 16: Rear Chassis Cover Screw Locations b.
  • Page 17 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 17: Removing the Rear Chassis Cover Step 10 : Remove the fan cover. a. Using a T7 Torx screwdriver, remove the two (2) screws securing the fan cover: Figure 18: Fan Cover Screw Locations b.
  • Page 18 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 19: Fan Cover Latches Operation Figure 20: Fan Cover Removal Step 11 : Remove the fan backflow guard. a. Using a T8 Torx screwdriver, remove the six (6) screws securing the fan backflow guard:...
  • Page 19 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 21: Fan Backflow Guard Screw Locations b. The fan backflow guard is a single piece of flexible material; remove it by lifting it away from the Chassis: Figure 22: Fan Backflow Guard Removal Step 12 : Remove the System Fan modules.
  • Page 20 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 23: System Fan Latch Operation Figure 24: System Fan Module Removal b. Repeat these steps to remove the remaining System Fan modules. Step 13 : Remove the Rack Ears and front system LED PCBA. a.
  • Page 21 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 25: Rack Ear Cover Screw Locations b. Pull each cover away from its rack ear to remove it: Figure 26: Rack Ear Cover Removal c. The left rack ear has a system LED PCBA mounted to it. Using a T7 Torx screwdriver, remove the two (2) screws holding the PCBA to the rack ear:...
  • Page 22 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 27: Front System LED PCBA Screw Locations d. On the PCBA, open the connector and separate the LED cable from the PCBA. Remove the PCBA and leave the LED cable in place. Figure 28: Front System LED PCBA Removal e.
  • Page 23 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 29: Rack Ear Screw Locations f. Remove each rack ear: Figure 30: Rack Ear Removal Remove the top cover assembly. Step 14 : a. Using a T7 Torx screwdriver, remove the fourteen (14) screws holding the top cover assembly to the Chassis:...
  • Page 24 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 31: Top Cover Assembly Screw Locations b. Lift the top cover assembly to remove it from the Chassis: Figure 32: Top Cover Assembly Removal Remove the rear system LED PCBA. Step 15 : a.
  • Page 25 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 33: Rear LED Access Panel Screw Locations b. Pull the bottom of the panel outward, and then pull the panel down to remove it from the Chassis: Figure 34: Rear LED Access Panel Removal c.
  • Page 26 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 35: Rear System LED PCBA Screw Locations d. On the PCBA, open the connector and separate the LED cable from the PCBA. Remove the PCBA and leave the cable in place: Figure 36: Rear System LED PCBA Removal Step 16 : Remove the fan bracket.
  • Page 27 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 37: Fan Bracket Screw Locations b. Lift the fan bracket to remove it from the Chassis: Figure 38: Fan Bracket Removal Step 17 : Remove the IOM bulkhead. a. Using a T7 Torx screwdriver, remove the two (2) screws from inside the bay for IO Module (IOM) B:...
  • Page 28 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 39: IOM-B Bulkhead Screw Locations b. Using a T7 Torx screwdriver, remove the two (2) screws from inside the bay for IO Module (IOM) A: Figure 40: IOM-A Bulkhead Screw Locations c.
  • Page 29 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 41: IOM Bulkhead Removal Remove power distribution board (PDB) B. Step 18 : a. Using a T7 Torx screwdriver, remove the three (3) screws from inside the bay for IO Module (IOM) B: Figure 42: PDB-B Screw Locations b.
  • Page 30 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 43: PDB-B Screw Locations c. Carefully pull PDB-B upward to separate it from its connector on the midplane and remove it from the Chassis: Caution: To prevent damage to the PDB leads and midplane connector, do not twist or torque the PDB when removing it from the midplane.
  • Page 31 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 45: PDB-A Screw Locations b. Using a T10 Torx screwdriver, remove the four (4) screws holding PDB-A to the midplane: Figure 46: PDB-A Screw Locations c. Carefully pull PDB-A upward to separate it from its connector on the midplane and remove it from the Chassis: Caution: To prevent damage to the PDB leads and midplane connector, do not...
  • Page 32 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 47: PDB-A Removal Remove the bottom drive guide plate. Step 20 : a. Using a T7 Torx screwdriver, remove the eighteen (18) screws holding the bottom drive guide plate to the Chassis. There are 9 screws inside each drive bay, and their locations mirror each other.
  • Page 33 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 49: Drive Guide Plate Bottom Screw Locations c. Pull the bottom drive guide plate forward to remove it from from the Chassis. This will expose the two (2) SSD LED PCBAs. Figure 50: Bottom Drive Guide Plate Removal Step 21 : Remove the SSD LED PCBAs...
  • Page 34 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 51: SSD LED Cable Removal b. Using a T10 Torx screwdriver, remove the three (3) screws from each PCBA: Figure 52: SSD LED PCBA Screw Locations c. Lift each PCBA to remove it from the Chassis:...
  • Page 35 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 53: SSD LED PCBA Removal Step 22 : Remove the midplane PCB. a. Using a T10 Torx screwdriver, remove the sixteen (16) screws holding the midplane PCB to the Chassis: Figure 54: Midplane PCB Screw Locations b.
  • Page 36 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 OpenFlex ™ Data24 Disassembly Figure 55: Freeing the Drive Connectors c. Lift the front edge of the midplane PCB until it is sitting at an upward angle. Then remove the midplane PCB. The LED cables should slide easily out from the locations where they are threaded into the Chassis.

  • Page 37: Io Module (Iom) Disassembly

    1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IO Module (IOM) Disassembly Figure 57: Removing the Midplane PCB   R esult:   T he OpenFlex™ Data24 Chassis is now disassembled.   W hat to do next:   P roceed with the IO Module (IOM) Disassembly (page 33) 1.5 ...
  • Page 38 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IO Module (IOM) Disassembly Figure 58: IO Module (IOM) Cannister Cover Screw Locations Slide the cover toward the rear of the IO Module (IOM) to remove it: Step 2 : Figure 59: IO Module (IOM) Cannister Cover Removal Step 3 : Using a T10 Torx screwdriver, loosen/remove the three (3) screws securing the PCIe support bracket to the IO Module (IOM) PCB.
  • Page 39 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IO Module (IOM) Disassembly Figure 60: PCIe Support Bracket Screw Locations Step 4 : Carefully pull the bracket upward to separate the connectors between the IO Module (IOM) riser PCB and IO Module (IOM) PCB: To prevent damage to the connectors, do not twist or torque the bracket Caution: when removing it from the IO Module (IOM).
  • Page 40 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IO Module (IOM) Disassembly Figure 61: PCIe Support Bracket Removal Step 5 : Using a T10 Torx screwdriver, remove the three (3) screws holding the AICs to the PCIe support bracket: Figure 62: AIC Screw Locations Step 6 : Carefully pull each AIC upward to separate its leads from the connector on the IO Module (IOM) riser PCB:...
  • Page 41 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IO Module (IOM) Disassembly To prevent damage to the cards and connectors, do not twist or torque Caution: the cards when removing them. Figure 63: AIC Removal Step 7 : Using a T10 Torx screwdriver, remove the three (3) screws holding the IO Module (IOM) riser PCB to the PCIe support bracket:...
  • Page 42 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IO Module (IOM) Disassembly Figure 64: IO Module (IOM) Riser PCB Screw Locations Step 8 : Lift the IO Module (IOM) riser PCB to remove it from the PCIe support bracket: Figure 65: IO Module (IOM) Riser PCB Removal Using a T10 Torx screwdriver, remove the six (6) screws holding the IO Module (IOM) PCB to the Step 9 : IO Module (IOM) cannister base:...
  • Page 43 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IO Module (IOM) Disassembly Figure 66: IO Module (IOM) PCB Screw Locations Step 10 : Using a 4.5mm nut driver, remove the stand-off screw near the connectors: Figure 67: IO Module (IOM) Stand-Off Screw Location Step 11 : Lift the IO Module (IOM) PCB to remove it from the IO Module (IOM) cannister base:...
  • Page 44 EcoDesign Disclosures 1.5 IO Module (IOM) Disassembly Figure 68: IO Module (IOM) PCB Removal   R esult:   T he IO Module (IOM) is now disassembled.   W hat to do next:   P roceed to OpenFlex Data24 Disassembly (page 4)
