TP48200A-HT19C3 and TP48200A-HT19C4
Telecom Power
User Manual
Issue
03
Date
2019-11-15
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Telecom Power TP48200A-HT19C3 and is the answer not in the manual?

Questions and answers

Related Manuals for Huawei Telecom Power TP48200A-HT19C3

Summary of Contents for Huawei Telecom Power TP48200A-HT19C3

  • Page 1 TP48200A-HT19C3 and TP48200A-HT19C4 Telecom Power User Manual Issue Date 2019-11-15 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: Preface

    NOTICE is used to address practices not related to personal injury. Supplements the important information in the main text. NOTE is used to address information not related to personal injury, equipment damage, and environment deterioration. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 4 Issue 03 (2019-11-15) Deleted contents about the app. Optimized the content about rectifiers. Issue 02 (2019-02-26) Optimized the content of the document. Issue 01 (2013-10-28) This issue is the first official release. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 5: Table Of Contents

    3.7.3 Water Sensor ................................39 3.7.4 Battery Temperature Sensor ............................. 39 3.7.5 Temperature Sensor in the Equipment Compartment ....................39 3.8 (Optional) Intelligent Electric Meter .......................... 39 3.9 (Optional) Bluetooth Door Lock ..........................41 Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 6 4.4.3 Replacing an AC SPD .............................. 58 4.4.4 Replacing a Circuit Breaker ............................. 59 4.4.5 Replacing the PCB of UIM02C ..........................61 4.4.6 Replacing the Internal Circulation Fan of the Heat Exchanger ................63 Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 7 C Associations Between Alarms and Dry Contacts on the UIM ........... 89 D Jumper Caps on the TCUA Control Board................90 E Cables Connection of TCUA Control Board ................. 91 F Acronyms and Abbreviations ....................92 Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 8: Safety Precautions

    The "NOTICE", "CAUTION", "WARNING", and "DANGER" statements in this document do not cover all the safety instructions. They are only supplements to the safety instructions. Huawei will not be liable for any consequence caused by the violation of general safety requirements or design, production, and usage safety standards.
  • Page 9 Before installing, operating, or maintaining a cabinet, clean up any water, ice, snow, or other sundries on the top of the cabinet to prevent sundries from falling into the cabinet when you open the cabinet door. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 10 To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telecommunication network voltage (TNV) circuits.  Do not power on the equipment before it is installed or confirmed by professionals. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 11 2. If there are multiple output ports, use the symbol near the output ports. Connect cables according to the rated power output and configuration parameter information in the instruction. 3. If there are multiple slots, use the symbol near the slot Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 12: Personnel Requirements

    1.2 Personnel Requirements  Personnel who plan to install or maintain Huawei equipment must receive thorough training, understand all necessary safety precautions, and be able to correctly perform all operations. ...
  • Page 13 When holding a board, hold its edge without touching any components. Do not touch the components with your bare hands.  Package boards with ESD packaging materials before storing or transporting them. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 14: Installation Environment Requirements

    Do not mount it on an insecure moveable object or metal object with sharp edges. Make sure that the hooks will not slide off. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 15: Mechanical Safety

    Before hoisting objects, ensure that hoisting tools are firmly secured onto a load-bearing object or wall.  Ensure that the angle formed by two hoisting cables is no more than 90 degrees, as shown in the following figure. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 16 75 degrees, as shown in the following figure. An angle rule can be used to measure the angle. When climbing a ladder, take the following precautions to reduce risks and ensure safety: Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 17 Moving Heavy Objects  Be cautious to avoid injury when moving heavy objects.  When moving the equipment by hand, wear protective gloves to prevent injuries. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 18: Battery Safety

     Dispose of waste batteries in accordance with local laws and regulations. Do not dispose of batteries as household waste. If a battery is disposed of improperly, it may explode. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 19  If permitted, disconnect the batteries in use before performing any other operations.  To avoid battery short-circuit, do not maintain batteries with power on. Flammable Gas Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 20 When the ambient temperature is lower than the lower limit of the operating temperature (charge is forbidden at 0° C), do not charge the battery. Otherwise, a short circuit would occur inside the battery.  Do not throw a lithium battery in fire. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 21 TP48200A-HT19C3 and TP48200A-HT19C4 Telecom Power User Manual 1 Safety Precautions  When maintenance is complete, return the waste lithium battery to the maintenance office. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 22: Overview

    The TP48200A-HT19C3 and TP48200A-HT19C4 are integration communications power systems that supply power to and back up power for -48 V DC outdoor communications equipment. Figure 2-1 shows the appearances of the two cabinets. Figure 2-1 Cabinet appearance Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 23: Model Number Description

    Network application over a fast Ethernet (FE) port and an RS485/RS232 port.  Communication with Huawei NetEco or third-party network management systems (NMSs) over protocols such as the Simple Network Management Protocol (SNMP) and Hypertext Transfer Protocol Secure (HTTPS) to enable remote management and unattended working.

  • Page 24: Configurations

    110 V AC dual-live wire four-wire input system, compatible with 220 V AC single-phase input system AC input circuit breaker One 3-pole 63 A circuit breaker One 2-pole 100 A circuit breaker Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 25 2 km away from medium pollution sources, such as chemical, rubber, and galvanization industries, and 1 km away from light pollution sources, such as packing houses, tanneries, and boiler rooms. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 26: Components

    TP48200A-HT19C3 and TP48200A-HT19C4 Telecom Power User Manual 3 Components Components 3.1 Interior TP48200A-HT19C3 Figure 3-1 shows the TP48200A-HT19C3 interior. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 27 (13) User interface (14) Site monitor module (15) DC power distribution module (UIM) (SMU02B) unit (PDU) (16) AC surge protection (17) AC input circuit breaker (18) Battery switch device (SPD) (behind the cover) Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 28 (2) (Optional) Intelligent (3) Cabinet ground bar transformer electric meter (4) (Optional) (5) Heat exchanger (HXC150S) (6) (Optional) Bluetooth Maintenance socket controller (7) (Optional) Electric (8) TCUA control box (9) TEC door lock Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 29: Pdu

    (4) BLVD circuit breakers (5) Battery circuit breakers The negative power cable of TCUA control box occupies the F10 BLVD circuit breaker. TP48200A-HT19C4 Figure 3-4 shows the PDU for the TP48200A-HT19C4. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 30: Battery Switch

    Open the cover and flip the battery switch to MANUAL only when you need to connect battery power supply manually. Remember to flip the battery switch back to AUTO after the commissioning. 3.3 Rectifier Rectifiers convert AC input into stable DC output. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 31 SMU has been interrupted. Fault indicator The rectifier is running properly. Steady on The rectifier has been locked out due to output overvoltage. The rectifier has no output due to an internal fault. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 32: Smu02B

    No minor or warning alarm is generated. indicator Steady on A minor or warning alarm is generated. Major alarm No critical or major alarm is generated. indicator Steady on A critical or major alarm is generated. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 33 After installing the specific WiFi module using the USB port, you can access the WebUI locally, which facilitates operations. Using WiFi modules provided by another vendor may cause data loss or function exception. Consequences arising from this will not be borne by Huawei. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 34 Table 3-5 Pin definitions for the FE port Signal Description Transmits data over FE. Receives data over FE. 4, 5, 7, 8 Table 3-6 Pin definitions for the RS485/RS232 port Signal Description Transmits data over RS485. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 35: Uim02C

    Sensor ports TEM-HUM Ambient temperature and humidity sensor WATER Water sensor TEMP1 Ambient temperature sensor 1 TEMP2 Ambient temperature sensor 2 GATE Door status sensor SMOKE Smoke sensor BTEMP Battery temperature sensor Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 36 Baud rate: 9600 bit/s, 19,200 M/S and Modbus protocol Connects to bit/s, 115,200 bit/s lower-level devices such as the battery inspection unit, DC air conditioner. NOTE The COM port supports the security mechanism. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 37 Sends data over RS485. PGND Connects to the ground. 3, 7, 8 None Pins Figure 3-11 shows the pin numbers of the sensor ports. Table 3-10 defines the pins. Figure 3-11 UIM02C pin numbers Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 38: Temperature Control Unit

    Internal circulation: Hot air in the equipment compartment is drawn by the internal circulation fan above the heat exchanger into the heat exchanger, passes through the heat exchanging Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 39: Tec

    Figure 3-12 Heat exchange working principles 3.6.2 TEC The TEC unit consists of the TEC module (TEC04C) and TCUA control box. It controls temperatures for the battery compartment. TEC Module (TEC04C) Figure 3-13 shows a TEC04C. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 40 (5) Internal circulation fan heat sink TCUA TCUA controls the operating of the fans and refrigeration chip, monitors the TEC, and reports alarms if faults occur. Figure 3-14 shows a TCUA. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 41 Meantime, the external circulation fan draws natural air into the external circulation heat sink to accelerate the airflow. The air absorbs the heat from the external Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 42: Sensor

    Figure 3-15 TEC airflow directions 3.7 Sensor Figure 3-16 shows the positions of all sensors in the TP48200A-HT19C3 & HT19C4. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 43 Figure 3-16 Sensors (1) Temperature sensor in the (2) (Optional) Ambient (3) Door status equipment compartment temperature and humidity sensor sensor (6) (Optional) (4) (Optional) Smoke sensor (5) Battery temperature sensor Water sensor Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 44: Smoke Sensor

    User Manual 3 Components 3.7.1 Smoke Sensor Figure 3-17 Smoke sensor 1 (1) Wiring port (2) Base (3) Indicator Figure 3-18 Smoke sensor 2 (1) Wiring port (2) Base (3) Indicator Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 45: Temperature And Humidity Sensor

    TP48200A-HT19C3 and TP48200A-HT19C4 Telecom Power User Manual 3 Components 3.7.2 Temperature and Humidity Sensor Figure 3-19 Temperature and humidity sensor 1 Figure 3-20 Temperature and humidity sensor 2 Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 46: Water Sensor

    An intelligent electric meter works together with a current transformer, and can measure the AC current, voltage, frequency, power factor, active power and total power and facilitates automatic management by communicating with the SMU over the RS485 port. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 47 Figure 3-23 Appearance of the current transformer Figure 3-24 Appearance and pins of the intelligent electric meter Table 3-12 Pin definitions of the intelligent electric meter Definitions Power supply RS485 communication Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 48: Optional) Bluetooth Door Lock

    The Bluetooth door lock consists of the electric door lock and Bluetooth controller which is used to control the electric door lock. 3.9.1 (Optional) Electric Door Lock Appearance Figure 3-25 shows an electric door lock. Figure 3-25 Electric door lock Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 49 Table 3-13 Port definitions of the electric door lock Definitions Description Sends data over RS485. Supplies power for the +12 V electric door lock Receives data over RS485. OPEN_DOOR Controls the electric door lock (reserved) Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 50: Optional) Bluetooth Controller

    TP48200A-HT19C3 and TP48200A-HT19C4 Telecom Power User Manual 3 Components 3.9.2 (Optional) Bluetooth Controller Appearance Figure 3-27 Bluetooth controller Port Definitions Figure 3-28 Ports on the Bluetooth controller Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 51 Table 3-14 Port definitions of the Bluetooth controller Definitions AC input AC input Connects to pin 4 Connects to pin 3 -12 V +12 V Controls the electric door lock (+) Controls the electric door lock (-) Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 52: Maintenance

    TEC04C The TEC04C works By observing, and The TEC module is Replace the checking the fan damaged and Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 53: Rectifying Common Faults

    AC input circuit breaker to turn OFF and then switch on the circuit breaker. Check whether the AC input voltage is lower than 50 V AC. If so, handle the power grid fault. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 54: Ac Over Volt

    Remove the rectifiers one by one and check whether the alarm is cleared. If the alarm still exists, reinstall the rectifier. If the alarm is cleared, replace the rectifier. 4.2.5 DC Under Volt Possible Causes  An AC power failure has occurred. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 55: Batt Chg. Overcur

    Check whether an AC power failure has occurred. If so, rectify the fault to restore the AC power supply. Check whether loads are manually disconnected. If so, check with other maintenance personnel whether the loads can be reconnected. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 56: Blvd Disconnected

    The high ambient temperature alarm threshold is incorrectly set.  The temperature control system is faulty in the cabinet where the ambient temperature sensor is located.  The ambient temperature sensor is faulty. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 57: Low Amb. Temp

    Check whether water intrudes into the cabinet. If yes, wipe the water with dry cotton or other tools and rectify the fault. Check whether the humidity sensor is faulty. If yes, replace the humidity sensor. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 58: Low Ambient Humidity

    This alarm is generated only for the power system that has a battery temperature sensor installed. Possible Causes  The low battery temperature alarm threshold is incorrectly set on the SMU.  The battery temperature control system is faulty.  The battery temperature sensor is faulty. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 59: Door Alarm

    4.2.18 Smoke Alarm This alarm is generated only for the power system that has a smoke sensor installed. Possible Causes  There is smoke inside the cabinet.  The smoke sensor is faulty. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 60: Rect Fault

    Rectifier connections are loose.  A rectifier is faulty. Measures Check whether a rectifier has been removed. If so, reinstall it. If the rectifier is in position, remove the rectifier and reinstall it. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 61: Load Loop Break

    4.3 Identifying Component Faults 4.3.1 Identifying AC SPD Faults Check the color of the AC SPD indication window. Green indicates that the AC SPD is normal. Red indicates the AC SPD is faulty. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 62: Identifying Circuit Breaker Faults

    The SMU cannot monitor AC or DC power distribution when communications cables are intact and AC and DC power distribution is normal.  Parameters cannot be set or running information cannot be viewed on the SMU. 4.4 Replacing Components Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 63: Replacing A Rectifier

    Step 6 Gently slide the rectifier into the slot along the guide rails until it is engaged. Close the handle, and push the locking latch towards the right to lock the handle, as shown in Figure 4-2. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 64: Replacing An Smu

    4 Maintenance Figure 4-2 Installing a rectifier Step 7 Remove the protective gloves. ----End Follow-up Procedure Pack the removed component and send it to the local Huawei warehouse. 4.4.2 Replacing an SMU Prerequisites  The cabinet door key is available.

  • Page 65: Replacing An Ac Spd

    4 Maintenance Figure 4-4 Installing an SMU ----End Follow-up Procedure Pack the removed component and send it to the local Huawei warehouse. 4.4.3 Replacing an AC SPD Prerequisites  An ESD wrist strap, ESD gloves, ESD box or bag, required tools, and cabinet door key are available.

  • Page 66: Replacing A Circuit Breaker

    Step 4 Loosen the screw that secures the lower port of the circuit breaker using a Phillips screwdriver, and open the buckle at the base of the circuit breaker using an insulated flat-head screwdriver. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 67 Step 9 Switch on the circuit breaker. Figure 4-7 shows how to install the new circuit breaker. Figure 4-7 Installing the new circuit breaker ----End Follow-up Procedure Check that the load fuse blown alarm has disappeared. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 68: Replacing The Pcb Of Uim02C

    Step 3 Unscrew and remove the UIM02C, as shown in Figure 4-8. Figure 4-8 Taking out the main board of UIM02C Step 4 Remove the –48 V power cable from the PCB of UIM02C. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 69 Step 11 Reconnect signal cables to the UIM02C panel based on the recorded information. Step 12 Disconnect the ground cable from the ESD wrist strap, and remove the ESD wrist strap and ESD gloves. ----End Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 70: Replacing The Internal Circulation Fan Of The Heat Exchanger

    Power User Manual 4 Maintenance Follow-up Procedure Pack the removed component and return it to the local Huawei warehouse. 4.4.6 Replacing the Internal Circulation Fan of the Heat Exchanger Prerequisites  Prepare an ESD wrist strap, a pair of ESD gloves, an ESD box or bag, the cabinet door key, and a maintenance tool kit.
  • Page 71 Reconnect signal cables to the UIM02C panel based on the recorded positions. Disconnect the ground cable from the ESD wrist strap, and take off the ESD wrist strap and ESD gloves. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 72: Replacing The External Circulation Fan Of The Heat Exchanger

    Step 3 Removing the external circulation fan. Record the position where cables connect to the external circulation fan, and then disconnect the cables. Remove the cover from the external circulation fan, as shown in Figure 4-14. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 73 TP48200A-HT19C3 and TP48200A-HT19C4 Telecom Power User Manual 4 Maintenance Figure 4-14 Removing the cover from the external circulation fan Remove the fan fixing plate from the external circulation fan, as shown in Figure 4-15. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 74 Install the fan fixing plate. Install the cover for the external circulation fan. Connect the removed cables to the external circulation fan based on the recorded positions. Step 5 Connect the transfer terminal. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 75: Replacing A Tcua Control Board

    Switch off the circuit breaker (F10) for the TCUA control box on the DC PDU. Record positions where cables connect to the TCUA control box and disconnect the cables. Unscrew and remove the TCUA control box, as shown in Figure 4-17. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 76 TP48200A-HT19C3 and TP48200A-HT19C4 Telecom Power User Manual 4 Maintenance Figure 4-17 Removing a TCUA control box Step 3 Remove the TCUA control board. Unscrew the TCUA control board, as shown in Figure 4-18. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 77 Switch on the circuit breaker (F10) for the TCUA control box on the DC PDU. Step 6 Disconnect the ground cable from the ESD wrist strap, and take off the ESD wrist strap and ESD gloves. ----End Follow-up Procedure Send the replaced TCUA for repair. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 78: Replacing A Tec

    Record the position where the TEC cable connect to the TCUA control board, and disconnect the cable. Unscrew and remove the external cover from the cabinet door, as shown in Figure 4-19. Unscrew and remove the TEC, as shown in Figure 4-20. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 79 TP48200A-HT19C3 and TP48200A-HT19C4 Telecom Power User Manual 4 Maintenance Figure 4-19 Removing the external cover from the cabinet door Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 80 Switch on the circuit breaker (F10) for the TCUA control box on the DC PDU. Step 6 Disconnect the ground cable from the ESD wrist strap, and take off the ESD wrist strap and ESD gloves. ----End Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 81: Replacing An Ambient Temperature And Humidity Sensor

    Step 3 Remove the temperature and humidity sensor, as shown in Figure 4-22. Hold down the button on the sensor and remove the sensor cover. Unscrew the sensor base. Record the positions where cables connect to the base and remove the cables. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 82: Replacing A Smoke Sensor

    Step 2 Remove the smoke sensor, as shown in Figure 4-23. Remove the connected cables from the smoke sensor. Hold down the button on the smoke sensor and push the smoke sensor in the OPEN direction. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 83 Place the new smoke sensor correctly and press and push it in the CLOSE direction. Reconnect the removed cables to the smoke sensor. Step 4 Disconnect the ground cable of the ESD wrist strap, and remove the ESD wrist strap and ESD gloves. ----End Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 84: Replacing A Battery Temperature Sensor

    Figure 4-24 Removing the battery temperature sensor cable Step 3 Cut off the cable tie of the battery temperature sensor and remove the sensor. The detection probe must not contact a metal surface. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 85: Replacing A Temperature Sensor For The Equipment Compartment

    Step 1 Connect the ground cable to the ESD wrist strap, and put on the ESD wrist strap and ESD gloves. Step 2 Remove the temperature sensor cable for the equipment compartment from the UIM, as shown in Figure 4-26. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 86 Step 5 Reconnect the temperature sensor cable to the UIM. Step 6 Disconnect the ground cable from the ESD wrist strap, and take off the ESD wrist strap and ESD gloves. ----End Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 87: Replacing A Water Sensor

    Step 2 Remove the water sensor cable from the UIM, as shown in Figure 4-28. Figure 4-28 Removing the water sensor cable Step 3 Cut off the cable tie of the water sensor and remove the water sensor. Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 88 Step 5 Reconnect the water sensor cable to the UIM. Step 6 Disconnect the ground cable from the ESD wrist strap, and take off the ESD wrist strap and ESD gloves. ----End Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 89: A Technical Specifications

    220 V AC single-phase  TP48200A-HT19C4: 110 V AC dual-live wire AC input voltage 85 V AC-300 V AC Input frequency Frequency range: 45-66 Hz; nominal frequency: 50 Hz or 60 Hz Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 90 60 kA (8/20 µs) DC surge Differential mode: 10 kA (8/20 µs); common mode: 20 kA (8/20 µs) protection Safety and Complies with the IEC/EN60950-1. regulatory design MTBF 200,000 hours Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 91: Emc Specifications

    Dimensions (H x W x D) 2030 mm x 820 mm x 760 mm (including the 150 mm high base) ≤ 200 kg (excluding rectifiers and batteries) Cabinet weight Protection level  Equipment compartment: IP55 Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 92: Hxc150S Heat Exchanger Specifications

    Item Specifications Rated voltage -48 V DC Rated cooling capacity (L32/L32) 200 W Heating capacity > 300 W Rated Cooling Power Consumption 300 W Operating environment -40° C to +40° C Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 93: Bluetooth Controller Specifications

    -45° C to +85° C A.8 Intelligent Electric Meter Specifications Table A-8 Intelligent electric meter specifications Item Specifications Dimensions (L x W x H) 72 mm x 76 mm x 63 mm Database update Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
  • Page 94 -10° C to +50° C Storage temperature -25° C to +75° C Relative humidity 20%-95% RH (non-condensing) Power input  18-90 V DC  Two options: 85-265 V AC or 85-330 V DC Power consumption Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 95: B Electrical Conceptual Diagram

    Figure B-1 Electrical conceptual diagram of the TP48200A-HT19C3 (220 V AC single-phase and 220/380 V AC three-phase four-wire) Figure B-2 Electrical conceptual diagram of the TP48200A-HT19C4 (110 V AC dual-live wire) Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 96: C Associations Between Alarms And Dry Contacts On The Uim

    AC surge protective device (SPD) faults or DC SPD faults ALM5 Battery or load fuse blown ALM6 Excessively high or low ambient and battery temperatures ALM7 Door status alarm ALM8 Fan faults Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 97: D Jumper Caps On The Tcua Control Board

    When replacing the TCUA control board, you can set the DIP switch for each temperature control equipment based on the following information. Figure D-1 Jumper caps on the TCUA control board Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 98: E Cables Connection Of Tcua Control Board

    Figure E-1 Cables Connection of TCUA Control Board (1) TEC refrigeration (2) TEC internal circulating (3) TEC external circulating chip (4) Power cable (5) TEC dry contact output (6) TEC temperature sensor port port Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.

  • Page 99: F Acronyms And Abbreviations

    International Electrotechnical Commission Mean time between failures MTBF Power distribution unit Site monitoring unit Simple Network Management Protocol SNMP Surge protection device Temperature control unit A TCUA Thermoelectric cooler User interface module Issue 03 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
