IMBER SMART – Industrial Series
Power Input
•
PIN
V+ (Red line)
V- (Yellow line)
PGND

3.5 Reset Button

Function Action
Press the RST button for less than 3 seconds in operating status
Reboot
Factory Reset
Run Normally
3.6 Inserting SIM cards
Inserting/removing SIM cards
•
1. Ensure the power is disconnected.
2. Use a Phillips screwdriver to remove the SIM slot cover.
3. Insert the SIM card(s) into the SIM socket.
4. Replace the SIM slot cover.
Description
Positive
Negative
GND
Press the RST button for 3 to 10 seconds until all LEDs blink a few times
and then reboot the router manually.
Press the RST button for more than 10 seconds. The router will run
normally without a reboot or factory reset.
