IMBER SMART – Industrial Series
DI/DO Interface
Type: 2 x DI + 2 x DO
•
Connector: terminal block
•
Isolation: 3KVDC or 2KVrms
•
Absolute maximum VDC: 36VDC
•
Absolute maximum ADC: 100mA
•
Other Interfaces
1× RST button
•
LED instruction: 1 x SYS, 1 x NET, 1 x USR, 3 x RSSI
•
Software
Network protocols: DHCP, ICMP, PPPoE, HTTP, HTTPS, DNS, VRRP, NTP...
•
VPN: IPSec, GRE, OpenVPN, DMVPN
•
Policy: RIPv1/RIPv2/OSPF/BGP dynamic route (optional)
•
Firewall & filter: Port forwarding, DMZ, anti-DoS, ACL
•
Serial port: TCP server and client, UDP
•
Management: Web, third-party platform
•
Power Supply and Consumption
Connector: 3-pin 3.5 mm female socket with lock
•
Input voltage range: 9~48VDC
•
Power consumption:
•
Idle: 100 mA@12V
Data link: 400 mA (peak) @12V
Physical Specification
Ingress protection: IP30
•
Housing and weight: Metal, 300g
•
Dimensions: 104mm x 104mm x 38mm (excluding antenna)
•
Installations: Din-rail mounting
•
Environmental
Operating temperature range: -40~+75℃
•
Storage temperature range: -40~+85℃
•
Operating humidity range: 5% to 95% (with no condensation)
•
