1 About this Guide Teldat S.A. Chapter 1 About this Guide This is the installation manual for the M10-Smart router and contains information on how to correctly install the device in a working environment. 1.1 Supported devices The information provided in this installation manual only applies to the M10-Smart router.
Page 9
TLDPM01E1 RCTM10SH005 AZW AW-XM458-TPU Quectel EM06-E TLDPM02E1 RCTM10SH006 AZW AW-XM458-TPU Quectel EM06-A 2.2 Characteristics 2.2.1 Power supply For further information on the different M10-Smart power supplies, please see Components and Power Supply page 5, Power source on page 11. M10-Smart...
Page 10
2.2.2 Hardware monitoring The LEDs on the front and the rear panel are used to monitor the hardware in the M10-Smart router. These LEDs provide visual information on the state of the device and reference the condition of the hardware components, indic- ating whether or not there is connectivity, data flow, etc.
Page 11
3 Components and Power Supply Teldat S.A. Chapter 3 Components and Power Supply The following chapter provides detailed information on the chassis of the M10-Smart router and its components. This information includes: • Components. • Information on assembly. • Power supply.
Page 12
Yellow -> Error, component operating incorrectly. Green -> System initialized and operating. 3.1.2 Rear panel The following figure shows the rear panel. Here you will find the majority of M10-Smart router connectors. Rear panel Fig. 3: The following table provides information on each connector, as well as a description:...
Page 13
4-port Ethernet LAN connections on page 13 LAN connectors on page 25 LAN interface on page 27 CONSOLE. Provides access to the M10-Smart local console for configuration and monitoring purposes. Connecting for configuration on page 16 Configuration connector on page 26...
Page 14
3 Components and Power Supply Teldat S.A. LAN LEDs Fig. 4: LAN Ethernet LED indicators Description Green - Steady: 10/100/1000M link established. - Blinking: Transferring data. Yellow - Steady: 1000M link established. None Interface is either unavailable, not installed, or not registered.
Page 15
3.2 Mounting an anti-theft security cable M10-Smart devices have been equipped with a standard Kensington security slot to which a security cable can be attached. The T-bar lock of the security cable allows the device to be attached to an anchor point, thus preventing potential thefts.
Page 16
Teldat S.A. 3.3.2 Wall mounting The M10-Smart can be mounted on the wall. There are two slots on the underside of the device, used to fix it to the wall. We recommend the following accessories for wall mounting, valid for solid and Gypsum board (plaster) walls: •...
Page 17
The M10-Smart does not have plug-in modules. Reserved for future use. 3.5 Power source The M10-Smart router is powered through an external AC/DC power adapter. Warning The equipment must be used with the power supply provided by the manufacturer. To power the router, plug the power supply into the mains supply and the DC connector.
Page 18
3 Components and Power Supply Teldat S.A. Fig. 11: DC Connector To avoid electric shocks, residual current circulation, and other unwanted effects that also affect communications, the following is recommended: Warning All interconnected communication devices should be plugged into THE SAME GROUNDED POWER OUTLET, which should at the same time be of good quality (lower than 10 ohms).
Page 19
3.7.2 WAN connections The M10-Smart has 2 Gigabit Ethernet interfaces for WAN connection. These ports have 2 connectors - SFP for an optical link and RJ45 for a 10/100/1000 Base-T link - but they cannot work simultaneously. Please pay careful attention to the labeling to avoid mistaking these ports for other types of ports: WAN connectors Fig.
Page 20
To assemble or dismantle the antennas, simply screw or unscrew them into or out of the SMA connectors located on the rear panel of the router. Installing these antennas in the M10-Smart is essential to improve the quality of the signal received and transmitted by the cellular model.
Page 21
3.7.4 Wireless LAN internal antennas The M10-Smart has two integrated antennas for a Wireless LAN module covering both the 2.4 GHz and 5 GHz bands. The WLAN module is internal and is only available for the Wi-Fi models.
Page 22
3.8 Installing the SIM card The M10-Smart router has a Wireless WAN interface that may need a SIM card to operate. The M10-Smart has one protected SIM tray located on its side panel, as shown in the following figure. Fig. 17: SIM tray To access the internal SIM, remove the SIM cover and insert the SIM card in its slot.
Page 23
4 Compliance Teldat S.A. Chapter 4 Compliance 4.1 Manufacturer information Brand Teldat Manufacturer Teldat S.A. Country Spain Postal Address Isaac Newton, 10 Parque Tecnológico de Madrid, 28760 Tres Cantos, Madrid, Spain International Phone +34 91 807 65 65 4.2 Risk identification WARNING: Signal word used to designate a potentially dangerous situation that may cause severe injuries or death if not avoided.
Page 25
This device is an Energy Related Product (ErP) with High Network Availability (HiNA) and automatically switches to a power-saving Network Standby mode when no packets have been transmitted for 10 minutes (set by default). When the M10-Smart is not needed, it can also be turned off disconnecting the power supply to save energy. M10-Smart...
Page 26
4 Compliance Teldat S.A. Network Standby: 7.2W All M10-Smart interfaces can be shut down individually. Check the configuration manuals to learn how to disable each interface. For further information, please see manual: Teldat “Dm772-I Configuration Interfaces” . 4.7 PSU energy efficiency...
Page 27
In accordance with Article 10 of 2014/53/EU, we inform you that national restrictions and requirements may apply for authorization purposes. These can change with time. Teldat S.A. recommends that you check with local authorities for the latest status of national regulations.
Page 28
31. 4.12 Intended use of the equipment The M10-Smart can be deployed as a Customer Premises Equipment (CPE) in enterprise branch offices or in envir- onments managed by the service provider. This product must only be used indoors.
Page 29
For further information, please see manual: “Teldat Dm830-I MNGPLAT feature” . A.2 Updating the software The M10-Smart router can be updated to new versions. Please contact your dealer for further details on new re- leases. There are several ways to update a Teldat router. For further information, please see manual: “Teldat Dm748-I Soft- ware Updating”...
Page 30
Technical Information Teldat S.A. A.3.1 Connecting using the local console (CONSOLE connector) The M10-Smart router has a RJ45 female connector on the front panel, known as CONSOLE, which provides ac- cess to the device's local console. CONSOLE Connector Fig. 18: To configure this, you must connect the Aux port to an asynchronous terminal (or to a PC with terminal emulation).
Page 31
Technical Information Teldat S.A. A.4.1 LAN connectors RJ45 LAN RJ45 PIN FE Signals GE Signals BI-DA+ BI-DA+ BI-DA- BI-DA- BI-DB+ BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.4.2 WAN Base-T connectors RJ45 WAN RJ45 PIN FE Signals GE Signals BI-DA+...
Page 36
Technical Information Teldat S.A. Bandwidth 802.11n: 20/40 MHz 802.11ac: 20/40/80 MHz 802.11ax: 20/40/80 MHz Integrated directional dual-band MIMO array Antenna A.5.7 USB 3.0 interface TERMINAL Two USB 3.0 (Super Speed) host ports. CONNECTOR Type-A. A.5.8 Configuration interface LOCAL TERMINAL RS-232 9600-8-N-1 without flow control.
Page 37
CE Radio Information Teldat S.A. Appendix B CE Radio Information This section includes some of the European radio frequencies that comply with CE regulatory requirements. Custom- ers may obtain additional country-specific bands upon request. B.1 RF WAN specifications WWAN connectivity is provided by an additional module installed on the router. The exact module installed will de- pend on your particular router model.
