IMBER SMART – Industrial Series
Syslog Information
Download Diagnosis
•
Downloads a Diagnosis file for analysis.
Download Syslog
•
Downloads the complete syslog since the last reboot.
Clear
•
Clears the syslog information displayed on the current page.
Refresh
•
Reloads the current page with the latest syslog information.

5.3 Link Management

This section shows how to configure the link management settings.

5.3.1 Connection Manager

Connection Manager->Status
Type
•
Displays the connection interface
Status
•
Displays the connection status for this interface.
IP Address
•
Displays the IP Address of this interface.
Netmask
•
Displays the subnet mask of this interface.
Gateway
•
Displays the gateway for this interface (used to route packets to remote networks).
