IMBER SMART – Industrial Series

2.3 General Specifications

Cellular Interface
• Standards: FDD-LTE/TDD-LTE, WCDMA/UMTS/HSPA/HSPA+/EDGE/GPRS,
• 2× SMA female antenna connector
• 2x SIM (3.0V and 1.8V)
Wi-Fi Interface
• Standards: 802.11b/g/n, 300Mbps
• 2x RP-SMA male antenna connector
• Supports Wi-Fi AP and Client modes
• Security: WEP, WPA and WPA2 encryption
• Encryption: TKIP, CCMP
GNSS Interface (optional)
Gen8C Lite of Qualcomm (GPS, GLONASS, BeiDou, Galileo, QZSS)
•
NMEA-0183
•
1x SMA female with 50 ohms impedance
•
Ethernet Interface
Standard: IEEE 802.3, IEEE 802.3u
•
4 x 10/100 Mbps, RJ45 connector
•
1x WAN interface (configurable on Web GUI)
•
1.5KV magnetic isolation protection
•
Serial Interface
1x RS232 (3 PIN): TX, RX, GND
•
1x RS485 (2 PIN): Data+(A), Data-(B)
•
Baud rate: 300 bps to 115200 bps
•
Connector: terminal block
•
15KV ESD protection
•
