Summary of Contents for Teldat ATLAS 60 NW
- Page 1 Manual Teldat S.A. ATLAS 6x/i6x NW Router Installation Manual Copyright© Teldat-DM632-I Version 1.1 September 2015 Teldat S.A. ATLAS 6x/i6x NW Router...
- Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
-
Page 3: Table Of Contents
Chapter 2 ATLAS 60 NW Routers ....... 3 Characteristics ........ - Page 4 Table of Contents Teldat S.A. Optional Storage ........
-
Page 5: Chapter 1 About This Guide
1 About This Guide Teldat S.A. Chapter 1 About This Guide This is the installation guide for the ATLAS 60 NW router and contains information on how to correctly install this device in a working environment. 1.1 Supported Devices The information provided in this installation guide only applies to the ATLAS 60 NW router family. -
Page 6: Related Documentation
1 About This Guide Teldat S.A. Fax: +34 918 076 566 Email: support@teldat.com 1.8 Related documentation Dm748-I Software Updating. Note The manufacturer reserves the right to make changes and improvements to either software or hard- ware of this product, modifying the specifications of this manual without prior notice. -
Page 7: Chapter 2 Atlas 60 Nw Routers
Virtual Private Networks through IPSec or L2TP, plus an extensive range of pro- tocols and IP routing functionalities. The ATLAS 60 NW router family can be expanded by means of a PMC card, allowing you to increase the range of interfaces in the device. -
Page 8: Chapter 3 Components And Power Supply
3 Components and Power Supply Teldat S.A. Chapter 3 Components and Power Supply The following chapter provides detailed information on the chassis of the ATLAS 60 NW router family and its com- ponents. This information includes: • Components. • Expansion modules. - Page 9 3 Components and Power Supply Teldat S.A. Below, you can find a description of each LED: Front panel LEDs table Description State Power-on indicator. It lights up when connected to the power. Shows the state of the device con- Off -> Device not connected, not de- nected to the USB connector.
-
Page 10: Rear Panel
3 Components and Power Supply Teldat S.A. Orange -> 10 Mbps: Flashes once 100 Mbps: Flashes twice 1000 Mbps: Flashes three times Green Ethernet (link) connection established Off -> Link has not been detected Green -> Flashes depending on the activity. -
Page 11: Top Panel
3 Components and Power Supply Teldat S.A. WWAN Main: main antenna for the ATLAS 60 NW cellular module. This module is optional, so your device may not have any antennas. Not supported. ON/OFF switch. Power cable connection. 3.1.3 Top Panel The following figure shows the top panel. -
Page 12: Expansion Slots
Teldat S.A. 3.2 Expansion Slots The ATLAS 60 NW has three expansion slots (SLOT 1, SLOT 2 and SLOT 3) that allow you to expand features and interfaces by inserting different cards or boards. 3.2.1 SLOT 1 - Expansion Slot SLOT 1 is located on the right hand side of the device’s... - Page 13 3 Components and Power Supply Teldat S.A. nection and the card standoff posts to the chassis. Location of the lateral connector for SLOT 1 expansion module Fig. 11: (6) Using a screwdriver, remove the cover covering the expansion slot. This cover is located on the front panel.
- Page 14 3 Components and Power Supply Teldat S.A. Current date: Mar 27 2013, Wednesday Current time: 12:56:57 System Info: PCB:0x128 GPPORCR:0x00280000 PVR:0x80212051 SVR:0x80EC0011 CLKs(KHz): CCB=393216 CPU0=786432 CPU1=786432 DDR(clk)=327680 LBUS=49152 Watchdog: Enabled MMU Mode: Dynamic ICache: ON; DCache: ON Write-Back; L2Cache: ON...
-
Page 15: Slot 2 - Expansion Slot
3 Components and Power Supply Teldat S.A. 3.2.2 SLOT 2 - Expansion Slot SLOT 2 is located on the left hand side of the device’s Rear Panel on page 6. In this case, we insert a PMC (PCI mezzanine card) into the SLOT. - Page 16 3 Components and Power Supply Teldat S.A. Inserting the PMC expansion card Fig. 18: (9) Screw the PMC board to the standoff posts using two screws and their corresponding washers. Firmly tighten the screws without damaging the board. Screwing down the PMC expansion card Fig.
-
Page 17: Slot 3 - Expansion Slot
3 Components and Power Supply Teldat S.A. GIGABIT ETHERNET 1 GIGABIT ETHERNET 2 LAN OVER SWITCH SWITCH(8) 10/100 CARD 0x18 POE CARD 1 SECURITY ENGINE Slot 1 - PCI device: PowerPC processor, Host (Bus: 10, Device: 0, Function: 0) (Vendor: 0x1957, Device: 0x0100) (Subs. - Page 18 3 Components and Power Supply Teldat S.A. To correctly insert the card, please follow these steps: (1) Switch off the device and remove the cables, as described in section Disconnecting on page 17. (2) Remove the device from the workplace and place it in a stable, safe location where it can be easily accessed and handled.
- Page 19 3 Components and Power Supply Teldat S.A. ************************************************** ************************************************** ************************************************** BIOS CODE DUMP....BIOS DATA DUMP..End of BIOS dump BIOS menu address: 0x4BD78 FLASH BIOS CODE VERSION: 02.01 6 2013 17:59:56 Current date: Mar 27 2013, Wednesday Current time: 12:56:57...
-
Page 20: Installation In A Rack
3.3 Installation in a rack The ATLAS 60 NW can be installed in a 19” rack. To do this, you need two plastic brackets like the ones shown be- low. The brackets and screws are not included in the basic packet and have to be acquired separately. -
Page 21: Internal Power Source
3 Components and Power Supply Teldat S.A. Workplace Conditions, Main Characteristics • Excessive cold and heat should be avoided, as should humidity and dust. • Direct exposure to sunlight should be avoided, as well as other heat sources. The device should not be placed amongst papers, magazines or other elements that could block natural air circulation. -
Page 22: Poe Source
Teldat S.A. 3.4.2 PoE Source The ATLAS 60 NW router can be powered through an Ethernet cable that complies with the PoE 802.3af standard (15.4 W per port). To use the PoE source option, you need to install a MiniPoE card. - Page 23 3 Components and Power Supply Teldat S.A. ************************************************** ************************************************** ************************************************** BIOS CODE DUMP....BIOS DATA DUMP..End of BIOS dump BIOS menu address: 0x4BD78 FLASH BIOS CODE VERSION: 02.01 6 2013 17:59:56 Current date: Mar 27 2013, Wednesday Current time: 12:56:57...
-
Page 24: Microswitches
Fig. 32: 3.5 Microswitches The ATLAS 60 NW router has a block of eight available micro-switches (located on the underside of the device) used for maintenance and test purposes. In this case, they are only used to load the default configuration. These switches should not be handled by the user other than to load the default configuration. - Page 25 3 Components and Power Supply Teldat S.A. When the device is switched on, a message similar to the one shown below will appear on the configuration con- sole: ************************************************** ************************************************** ************************************************** BIOS CODE DUMP....BIOS DATA DUMP..End of BIOS dump FLASH BIOS CODE VERSION: 02.01...
-
Page 26: Data Connection
3.6.3 Connecting a USB 3G device (USB connector) The ATLAS 60 NW router has a USB HOST 2.0 interface with a type A connector that allows USB 3G modems to be connected. The interface is activated through the corresponding software license. -
Page 27: Optional Storage
3 Components and Power Supply Teldat S.A. 3.6.4 Connecting for Configuration The ATLAS 60 NW router has a RJ45female connector on the front panel known as “ Conf.” , which provides access to the device's local console. For further information, please see section Connecting to the device on page 27. -
Page 28: Procedure To Install A Flash Memory Expansion Usb
3 Components and Power Supply Teldat S.A. Location of the SATA connector and standoffs for the hard disk Fig. 37: (5) Screw the hard disk supplied to the auxiliary metal plate. (6) Connect the hard disk and place the metallic flange carefully over the standoff posts located in the device chassis. - Page 29 3 Components and Power Supply Teldat S.A. Location of the USB connector for the flash memory expansion Fig. 38: (5) Close the device with the cover. Secure the cover with the screws. (6) Connect and switch on the device, as described in section Connecting on page 17.
-
Page 30: Appendix A Technical Information
A.2 Updating the software The ATLAS 60 NW router can be updated to new releases. Please contact your distributor for further details on new releases. There are various ways to update a Teldat router. For further information, please see manual “ Dm748-I Software Up- dating”... -
Page 31: Connecting To The Device
A.3 Connecting to the device A.3.1 Connecting using the local console (Conf connector) The ATLAS 60 NW router has a RJ45 female connector on the front panel known as “ Conf .” , which provides access to the device local console. -
Page 32: Lan (Ge X) Connector
Technical Information Teldat S.A. A.4.1 LAN (GE x) Connector RJ45 PIN FE Signals GE Signals RJ45 LAN BI-DA+ BI-DA+ BI-DA- BI-DA- BI-DB+ BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- Note The Ethernet connectors have a MDI-X and auto-polarity auto-detection feature that acts bidirectionally. -
Page 33: Configuration Connector
Technical Information Teldat S.A. A.4.4 Configuration Connector CONF RJ45 CONFIGURATION A.5 Technical Specifications A.5.1 Hardware Architecture PROCESSOR FreeScale QorlQ P1020E MEMORY 512 Mbytes in DDR3 STORAGE UNIT FLASH NOR Memory (64 Mbytes) EEPROM 2Kbytes, NVRAM 128Kbytes A.5.2 LAN Interfaces* PROTOCOLS Ethernet (802.3) -
Page 34: Power Supply
Technical Information Teldat S.A. A.5.4 Power Supply INPUT VOLTAGE 100-240 V AC INPUT CURRENT 1.8 A INPUT FREQUENCY 50/60 Hz MAXIMUM POWER 100 VA A.5.5 Dimensions and weight TYPE Box to assemble in a Rack 1U high LENGTH x WIDTH x HEIGHT 440 x 378,71 x 43.2 mm... -
Page 35: Appendix B Regulatory Compliance And Safety Information
B.1 Recycling and the Environment Please do not, under any circumstances, throw away any ATLAS 60 NW with normal domestic waste. Ask your local town hall for information on how to correctly dispose of them in order to protect the environment against e-waste. Al- ways respect the current laws regarding waste material. -
Page 36: Translated Safety Warnings
Regulatory compliance and safety information Teldat S.A. B.2 Translated Safety Warnings ATLAS 6x/i6x NW Router... - Page 37 Regulatory compliance and safety information Teldat S.A. Connecting Disconnecting ATLAS 6x/i6x NW Router...
-
Page 38: Compliance
Regulatory compliance and safety information Teldat S.A. B.3 Compliance B.3.1 FCC Statement B.3.1.1 Federal Communications Commission Interference This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a com- mercial environment.
