Bit
Byte
09
10
11

Field Definitions

Logical Unit Number (Byte 01, bits 7-5)
The library does not support Logical Unit Numbers, so this field must be 0.
Transport Element Address (Bytes 02 - 03)
This field is ignored by the library. There is only one transport element.
Source Address (Bytes 04 - 05)
This is the element location (address) from where the data cartridge is to be taken. This
may be a storage location, the Entry/Exit Port or a CTS.
Destination Address (Bytes 06 - 07)
This is the element location (address) where the data cartridge is to be placed. This may
be a storage location, the entry/exit port or a CTS.
Invert (Byte 10, bit 0)
The library does not support the Invert function. The valid value for this field is 0.
Clean (Byte 11, bit 6)
Upon receipt of a Clean command the library moves the cleaning cartridge from the
source location to the destination. Once the drive is through cleaning, this command
returns the cartridge to the original source location.
Chapter 8
7 6 5
Reserved
RSVD Clean Reserved
4 3 2 1 0
Invert
0 0
