First Data Transfer Element Address (Bytes 14 - 15)
The First Data Transfer Element Address field identifies the address of the first location
for the installed drives. The library can have between 1 and 4 Data Transfer Elements
(tape drives) installed. The default value for this field is 80. See the table on page 62 for
more information.
Number of Data Transfer Elements (Bytes 16 - 17)
The Number of Data Transfer Elements field identifies the total number of drives
installed in the library. The library can have one to four drives installed. Therefore, the
value for this field can be 01h to 04h depending upon the number of drives installed. See
the table on page 62 for more information.
