Read Element Status Data Format

Bit
Byte
00
-
01
02
-
03
04
05
06
07
08
to
nn

Field Definitions

First Element Address Reported (Bytes 00 - 01)
This field indicates the smallest element address found that meets the CDB requirements.
Number of Elements Reported (Bytes 02 - 03)
This field indicates the total number of element descriptors available that meet the CDB
requirements. Status for these elements are returned if sufficient allocation length is
specified.
7 6 5 4
(MSB)
First Element Address Reported
(LSB)
(MSB)
Number of Elements Reported
(LSB)
Reserved
(MSB)
Byte Count of Report Available
(LSB)
Element Status Page(s)
3 2 1 0
