Vendor-unique Parameter List Format (00h)

Bit
Byte
00
01
02
03
04
05
06
07
08
09

Field Definitions

PS (Byte 00, bit 7)
The Save Page field identifies whether or not this page can be saved to FPROM. 0 = not
savable, 1 = savable. The value for this page is 1.
Page Code (Byte 00, bits 5-0)
The Page Code identifies the Vendor-unique Parameter List. The value of this field must
be 00h.
Parameter List Length (Byte 01, bits 7-0)
The Parameter List Length is 8, indicating that there are 8 additional bytes of parameter
data that follow this byte.
7 6 5
PS RSVD Page Code
Parameter List Length
Reserved
Queued Unload
Lock Touch Screen
Reserved
Reserved
Reserved
Reserved
Reserved
4 3 2 1
Auto ChkSum EBarCo
0
