10kdev_.book Page 73 Friday, March 12, 1999 9:44 AM
Bit
Byte
12
13
14
15
DT-Cartridge Tape Subsystem (Tape Drive) ST-Storage Location (Storage Carousel)
I/E-Entry/Exit Port (Rotary Door)

Field Definitions

PS (Byte 00, bit 7)
The Save Page field identifies whether or not this page can be saved to FPROM. 0 = not
savable, 1 = savable. This page is not savable, i.e. the value for this page is zero.
Page Code (byte 00, bits 5-0)
The Page Code identifies the Device Capabilities Parameter List. The value returned for
this field is 1Fh.
Parameter Length (Byte 01, bits 7-0)
The Parameter Length is 12h, indicating that there are an additional 18 bytes of
parameter data to follow this byte.
StorDT (Byte 02, bit 3)
This field identifies the ability of the data transfer element (tape drive) to perform the
function of storage. The value returned for this field is 1.
7 6 5 4
Reserved
MT-Media Transport (Gripper Arm)
3 2 1
MT<>DT MT<>IE MT<>ST
0 0 0
ST<>DT ST<>I/E ST<>ST
0 0 0
I/E<>DT I/E<>I/E I/E<>MT
0 0 0
DT<>DT DT<>I/E DT<>ST
0 0 0
0
MT<>MT
0
ST<>MT
0
I/E<>MT
0
DT<>MT
0
