Parameter List Length (Byte 01, bits 7-0)
The valid value for this field is 12h indicating there are an additional 18 bytes of Element
Address data that follow this byte.
Medium Transport Element Address (Bytes 02 - 03)
The Medium Transport Element Address field identifies the address of the Gripper Arm
Mechanism. The library has only one gripper arm, whose default value is 79. See the table
on page 62 for more information.
Number of Medium Transport Elements (Bytes 04 - 05)
The Number of Medium Transport Elements field identifies the number of gripper arms
within the library. The library has only one gripper arm. The value for this field must be
01h.
First Storage Element Address (Bytes 06 - 07)
The First Storage Element Address field identifies the starting address of the carousel
slots. The default starting address is 01h. See the table on page 62 for more information.
Number of Storage Elements - (Bytes 08 - 09)
The Number of Storage Elements field identifies the number of carousel slots within the
library. This field varies depending on the configuration of the library. See the table on
page 62 for more information.
First Import/Export Element Address (Bytes 10 - 11)
The First Import/Export Element Address field identifies the address of the entry/exit
port. The library has only one entry/exit port. The default address is 00h.
Number of Import/Export Elements (Bytes 12 - 13)
The Number of Import/Export Elements field identifies the total number of elements
used for Import/Exporting Elements (rotary door). The library has only one Import/
Export Element, so this field must be 01h.
