Field Definitions

PS (Byte 00, bit 7)
The Save Page field identifies whether or not this page can be saved to FPROM. 0 = not
savable, 1 = savable. The value for this page is 1, i.e. these values cannot be modified.
Page Code (Byte 00, bits 5-0)
The Page Code identifies the Element Address Assignment Parameter List. The value
returned for this field is 1Dh.
Parameter List Length (Byte 01, bits 7-0)
The value returned for this field is 12h (18), indicating that there are an additional 18
bytes of parameter data that follow this byte.
Chapter 7
Bit 7 6
Byte
10
(MSB)
-
First Import/Export Element Address
11
(LSB)
12
(MSB)
-
Number of Import/Export Elements
13
(LSB)
14
(MSB)
-
First Data Transfer Element Address
15
(LSB)
16
(MSB)
-
Number of Data Transfer Elements
17
(LSB)
18
Reserved
19
Reserved
5 4 3 2 1 0
