Medium Transport Element Address (Bytes 02 - 03)
The Medium Transport Element Address field identifies the address of the Gripper Arm
Mechanism. The library has only one Gripper Arm.
Number of Medium Transport Elements (Bytes 04 - 05)
The Number of Medium Transport Elements field identifies the number of Medium
Transport Elements within the library. This field varies depending on the configuration
of the library. See the table in on page 62 for more information.
First Storage Element Address (Bytes 06 - 07)
This field identifies the starting address of the carousel slots.
Number of Storage Elements (Bytes 08 - 09)
This field identifies the number of carousel slots within the library, and thus varies
depending on the configuration of the library. See the table in on page
62 for more information.
First Import/Export Element Address (Bytes 10 - 11)
The First Import/Export Element Address field identifies the address of the rotating door.
The library has only one entry/exit port. See the table in on page 62
for more information.
Number of Import/Export Elements (Byte 12 - 13)
The Number of Import/Export Elements field identifies the total number of entry/exit
ports used for importing and exporting data cartridges; the library only has one port.
First Data Transfer Element Address (Byte 14 - 15)
The First Data Transfer Element Address field identifies the address of the first location
for the installed tape drive. The library can have 1 to 4 Data Transfer Elements. This field
varies depending on the configuration of the library. See the table in
on page 62 for more information.
