Field Definitions

Mode Data Length (Byte 00, bits 7-0)
The Mode Data Length specifies the length of mode data, in bytes, that is available to be
transferred.
LCD Mode:
Bit
Byte
00
01
02
03
04:23
24:43
44:63
64:83
PS - Byte 00, Bit 07 (Page Savable)
This field specifies that the library is capable of saving this page to nonvolatile memory.
The value returned for this field is 1.
Parameter List Length - Byte 01
The parameter length is 52h (82) which indicates that there are an additional 82 bytes of
data that follow this byte.
Front Panel Lock - Byte 02, Bit 07
This bit indicates that if the Front Panel is locked, the door may be unlocked (enabled
for use). This would allow access to the door by users, but not other front panel functions.
The values for this bit are as follows:
7
6
5
4
PS
RSVD
Page Code (22h)
Parameter List Length
Door
Front
Reserved Write
Unlock
Panel
Lock
Reserved
Display Line 1
Display Line 2
Display Line 3
Display Line 4
3
2
1
0
Write
Write
Write
Line 1
Line 2
Line 3
Line 4
