Byte Count of Report Available (Bytes 05 - 07)
This field indicates the total number of element status data available that meet the CDB
requirements. This value is not adjusted to match the allocation length available.

Element Status Page Format

This header is sent once for each group of element descriptors of the same type.
.

Field Definitions

Element Type Code (Byte 00, bits 7-0)
This field specifies the particular element types reported by this page. The element type
codes are defined below:
00h All Element Types reported
01h Medium Transport Element (Gripper Arm Mechanism)
Chapter 11
Bit 7 6
Byte
00
Element Type Code
01
PVolTag AVolTag
02
(MSB)
-
Element Descriptor Length
03
(LSB)
04
Reserved
05
(MSB)
06
Byte Count of Descriptor Data Available
07
(LSB)
08
to
Element Descriptor(s)
nn
5 4 3 2 1
Reserved
0
