Enter/Exit Programming Mode

Maxicode Length Control

This feature specifies either variable length decoding or fixed length decoding for this symbology.
Variable Length: For variable length decoding, a minimum and maximum length may be set.
Fixed Length: For fixed length decoding, two different lengths may be set.
DEFAULT
$CMXLC01(CR)
Maxicode Length Control = Fixed Length
Maxicode
Set Length 1
Specifies one of the bar code lengths for
Variable Length Mode, or the first fixed length if in Fixed Length Mode. Characters can be set from 0001 to 0145
characters in increments of 0001 (pad with zeroes).
See page 217 for detailed instructions on setting this feature.
$CMXL1
Select Maxicode Length 1 Setting
Make a mistake? Scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the
beginning.
186
Maxicode Length
DEFAULT
$CMXLC00(CR)
Maxicode Length Control = Variable Length
Control. Length 1 is the minimum label length if in
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code
at left followed by the digits from the Alphanumeric
Appendix D, Keypad
characters in
desired character(s). End by scanning the ENTER/EXIT
bar code again.
~
0001 = Length 1 is 1 Character
representing your
CANCEL
QuickScan™ I QD24XX
