Enter/Exit Programming Mode

MULTIPLE LABEL READING

In standard (default) mode, when the reader's aiming system is activated (by a trigger pull, motion or other method
depending on the mode), it then acquires and processes each image in the area in front of it (the Volume). In this
case, the scanner stops processing the image once it decodes a label. If several labels are present in the volume, only
the first label encountered is decoded and sent.
When Multiple Reading Mode is enabled, the scanner keeps on processing the image until all the labels present are
decoded. The reader then sorts the data from all the bar codes (if configured to do so) before transmitting it.

Multiple Labels per Frame

Specifies the ability of the reader to decode and transmit a set of code labels in a specific volume and in a single
frame of time. When in Multiple Labels per Frame the reader beeps and turns on the good read LED indication for
each code read in a frame.
When Multiple Labels Mode is enabled, ISBT pairing, ABC Codabar pairing, and composites are not allowed.
$CSNML00(CR)
DEFAULT
Multiple Labels per Frame = Disable
$CSNML01(CR)
Multiple Labels per Frame = Enable
