2D Symbologies; 2D Global Features - Datalogic QuickScan I QD24 Series Product Reference Manual

• 2D Maximum Decoding Time on page 174
• 2D Structured Append on page 175
The reader supports the following 2D symbologies (bar code types). Symbology-dependent options for each
symbology are included in this chapter. See
codes.
• Aztec Code on page 176
• China Sensible Code on page 179
• Data Matrix on page 182
• Maxicode on page 185
• PDF417 on page 188

2D Global Features

The following features are common to all, or in some cases, most of the available 2D symbologies. Default settings
are indicated at each feature/option with a green arrow. Also reference
of the most widely used set of standard factory settings. That section also provides space to record any custom
settings needed or implemented for your system.
To set most features:
1. Scan the ENTER/EXIT PROGRAMMING bar code at the top of applicable programming pages.
2. Scan the correct bar code to set the desired programming feature or parameter. You may need to cover unused
bar codes on the page, and possibly the facing page, to ensure that the reader reads only the bar code you
intend to scan.
3. If additional input parameters are needed, go to
from the keypad.
Additional information about many features can be found in the "References" chapter.
If you make a mistake before the last character, scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the beginning.
Complete the programming sequence by scanning the ENTER/EXIT PROGRAMMING bar code to exit
Programming Mode.
Product Reference Guide

2D SYMBOLOGIES

2D Global Features
"1D Code Selection"
2D Symbologies
Appendix D,
• 2D Normal/Inverse Symbol Control on page 175
starting on page 81 for configuration of 1D bar
• Micro PDF417 on page 191
• QR Code on page 194
• Micro QR Code on page 197
• UCC Composite on page 200
• Postal Code Selection on page 202
Appendix B, Standard Defaults
Keypad, and scan the appropriate characters
for a listing
173
