2. Resistance programming accuracy differs based on different output current.
For example, 10A Transient 1.0Ω, accuracy: (1.0Ω * 0.25%) +(375mΩ*A /10A)
= 40mΩ.1.0Ω, accuracy: (1.0Ω * 0.25%) +(375mΩ*A /10A) = 40mΩ.
3. Set value accuracy means the set accuracy realized through the panel button
or communication instructions. When external analog is used for programming,
the programming accuracy is 2%FS.
4. Read-back value accuracy means the read-back accuracy realized through
panel display or communication instructions; when external analog is used for
monitoring, the monitoring accuracy is 1%FS.
5. Up time and down time mean the time of establishment from one value to
another value under ON status when the internal standard power dissipater is
enabled.
6. Use 12V/120AH battery for test.
7. When used in parallel, to balance power of each phase, distribute the
instrument to three phases. But must ensure that single machine input voltage
meets Specification requirements.
8. It means the maximum phase current value under minimum work input
voltage.

5.1.10 IT6515C

Parameter
Output Rating ( 0 ℃-40
℃)
Output Resistance
Line regulation
±(％of Output+Offset)
Load regulation
±(％of Output+Offset)
Setup Resolution
Output Voltage
Output Current
Internal Sink Current
Output Power
Internal Sink Power 1
Range
Accuracy 2
Resolution
Voltage
Current
Voltage
Current
Voltage
Current
Copyright © Itech Electronic Co., Ltd.
IT6515C Ver:V1.6
1
0～1800W
0～138.88Ω
0.25%+200mΩ
≤0.01%+50mV
≤0.01%+10mA
≤0.01%+100mV
≤0.05%+20mA
Technical Specification
0～500V
0～20A
0～8A
0～150W
10mΩ
100mV
10mA
117
