Set load input
When using load function, the user can set load current, power and slope as
well as OCP, OPP, etc.
In internal load mode, the value of load power is defaulted to rated value, and
the value of current is defaulted to a small value. In external load mode, the
values of load power and current are defaulted to zero.
Set the load input current and input power in Setup menu. Details about load
input current/power are as shown below.
1. Press [Shift]+ [V-set](Setup) to enter the Menu operation. The interface
2. Select Load to set parameters related to the load.
3. Press the Number key or use Knob to directly set the power or current value.

3.9.9 Setting Filter

This option sets the display filter frequency of the power supply. The filter
function of this series of power supply is averaging calculation. The average
values of different frequencies are different, as shown below: Low: 2^16; Mid:
2^14; High: 2^8.
1. Press composite keys [Shift]+[P-set](Menu) enter to system menu.
2. Select CONFIG, press [Enter] to confirm.
3. Select Filter with Left/Right key and press [Enter] to confirm.
4. Select Low, Mid or Fast with Left/Right key and press [Enter] to confirm.
On: the current load function is on. The user can select On or Off to turn on
or off the load function through Up/Down key. When the load is on, you need
to select internal load or external load. The instrument defaults to internal
load.
Internal: the current load is internal load. The user can select Internal (-
internal load) or External (external load) through Up/Down key.
When the number of the power dissipater for external load changes, the load
limit value needs to be changes manually.
displays information as follows:
LOAD
P-set I-set
•
Select P-set to set the input power value.
•
Select I-set to set input current value.
Copyright © Itech Electronic Co., Ltd.
Slope OCP
Function and Features
31
