ITech IT6500C Series User Manual page 63

SAEJ1113- SAEJ1113-11 waveform protocol
11
Test 2B
Test 4
Test 5
Copyright © Itech Electronic Co., Ltd.
Function and Features
Off Turn on /off startup
pulse
On
Transient from DC motors acting as
generators after ignition switch OFF
Off Turn on/off this
function
On
12V Select 12V or 24V
voltage system
24V
Td Test pulse width
Starter motor engagement
disturbance pulse
Off Turn on/off this
function
On
12V Select 12V or 24V
voltage system
24V
Vs Refer to the figure
Va -
T7 -
T9 -
T11 -
Load dump waveform
Test A select centralized
load dump
Unsuppression
Test B select centralized
load dump
suppression
Off Turn on/off load dump
waveform
On
12V Select 12V or 24V
voltage system
24V
52
