5. Up time and down time mean the time of establishment from one value to
another value under ON status when the internal standard power dissipater is
enabled.
6. Use 12V/120AH battery for test.
7. When used in parallel, to balance power of each phase, distribute the
instrument to three phases. But must ensure that single machine input voltage
meets Specification requirements.
8. It means the maximum phase current value under minimum work input
voltage.

5.1.11 IT6525C

Parameter
Output Rating ( 0 ℃-40
℃)
Output Resistance
Line regulation
±(％of Output+Offset)
Load regulation
±(％of Output+Offset)
Setup Resolution
Read Back Resolution
Setup Accuracy
（within 12 months,25℃
±5℃)
±(％of Output+Offset)
Output Voltage
Output Current
Internal Sink
Current 1
Output Power
Internal Sink
Power 1
Range
Accuracy 2
Resolution
Voltage
Current
Voltage
Current
Voltage
Current
Power
Voltage
Current
Power
Voltage
Current
Power
Copyright © Itech Electronic Co., Ltd.
Technical Specification
IT6525C Ver:V1.6
0～500V
0～20A
0～8A
0～3000W
0～150W
0～83.33Ω
0.25%+200mΩ
10mΩ
≤0.01%+50mV
≤0.01%+10mA
≤0.01%+100mV
≤0.05%+20mA
100mV
10mA
0.1W
100mV
10mA
0.1W
≤0.05%+200mV
≤0.2%+20mA
≤1%+30W
120
