6. After editing the above parameters in step 1, continue to edit the same
7. Select Save to Wave to save, and press [Enter] for confirmation. Select
Editing List File
List file editing means to arrange and link several Waves in certain sequence.
Take an example for 3 wave files, the steps of editing list file are as follows:
1. Press [Shift]+[I-set](Function) to enter List operation.
2. Press the Right key to select EditFile from the menu.
3. Press the numeric key to set the count of repetitions in executing this List
4. Press the numeric key to set the count of Waves contained in this List. For
5. Press the numeric key to input the number and count of repetitions of the
6. Press the numeric key to input the number and count of repetitions of the
Step1 Slope = 0.1s
When CV mode is selected from CC/CV Priority, the load current value
set in List wave file fails and discharge current is the I-set value set in the
power supply Setup menu. Pay attention to current value to avoid over-
current. For detailed checking and setting methods, refer to
Function.
When CC mode is selected from CC/CV Priority, the two-quadrant
current slope is only affected by the hardware and cannot be changed by
the setting parameter, but the one-quadrant current slope can be
controlled by the setting parameter.
parameters for step 2 and step 3. Count of steps is up to customer
requirements. At most 10 steps can be edited. The edited Step Count shall
be consistent with the one defined by the customer.
Yes. After editing, select Yes or No. Select Yes to save to the Wave file.
Select No not to save and return back to the List Setting screen.
file. For example, if there are 2 repetitions, Repeat = 2.
Repeat = 2
example.
Wave Count = 3
first Wave selected.
1st Wave Select = 02
1st Wave Repeat = 1
second Wave selected.
