Technical Specification
Parameter IT6537C Ver:V1.4
Command Response
20mS
Time
Power Factor 0.99
Maximum input current 8
38A
Maximum input apparent
7600VA
power
Storage temperature
-10℃～70℃
Source OVP, OCP, OPP and Load OCP, OPP, OTP,Vsense
Protective function
standard Interface USB/RS232/CAN/LAN
Isolation ( output to
1000V
ground)
Parallel Number ≤8
Working temperature
0～40℃
Dimension ( mm)
483mmW×194mmH×640.8mmD
Weight( net) 35Kg
The above specifications may be subject to change without prior notice.
1. Internal absorption current and internal absorption power mean the
absorption current and power of the standard power dissipater inside the power
supply.
2. Resistance programming accuracy differs based on different output current.
For example, 10A Transient 1.0Ω, accuracy: (1.0Ω * 0.25%) +(375mΩ*A /10A)
= 40mΩ.1.0Ω, accuracy: (1.0Ω * 0.25%) +(375mΩ*A /10A) = 40mΩ.
3. Set value accuracy means the set accuracy realized through the panel button
or communication instructions. When external analog is used for programming,
the programming accuracy is 2%FS.
4. Read-back value accuracy means the read-back accuracy realized through
panel display or communication instructions; when external analog is used for
monitoring, the monitoring accuracy is 1%FS.
5. Up time and down time mean the time of establishment from one value to
another value under ON status when the internal standard power dissipater is
enabled.
6. Use 12V/120AH battery for test.
7. When used in parallel, to balance power of each phase, distribute the
instrument to three phases. But must ensure that single machine input voltage
meets Specification requirements.
