3.11 Setting Output Rise Time/Fall Time

Rise/fall time is the time taken for one voltage point to rise/fall to the other under
the output status is ON. When view the fall time that voltage falls to 0V, set 0V
through [V-set]. After press [Enter] to confirm, voltage will fall based on the set
fall time.
This series of power supply is supported the rise and fall times in all modes(-
Source: CV, CC, CP, Load: CC, CP) , the range of time is 0.001S to 24H.
1. Press [Shift] + [V-set](Setup) to enter power supply setting screen.
2. Select "Source", press [Enter].
3. Select Slope.

3.12 Protection Function

IT6500CSeries provides OVP, OCP, OPP for power supply as well as OCP and
OPP for the load. In addition, this power supply also provides OTP, Sense
reverse protection, power-down protection and input under-voltage protection.
Or, the user can select Load to set the load slope.
You can set the rise/fall times for voltage, current and power. The unit is
second (S). Each setting can be selected through the Up/Down key. Adjust
the rise time through the numeric key, Up/Down key or knob. After input,
then press [Enter] or [OK] for confirmation.
•
V-Rise/ V-Fall: Voltage rise/fall slope.
•
I-Rise/ I-Fall: Current rise/fall slope.
•
P-Rise/P-Fall: Power rise/fall slope.
The drop rate of the voltage is affected by the internal load input current.
Setting the load input current to the maximum will get the drop rate of the
voltage up. Please refer to the Set load input in
more detailed setting.
When CC mode is selected from CC/CV Priority, the two-quadrant
current slope is only affected by the hardware and cannot be changed by
the setting parameter, but the one-quadrant current slope can be
controlled by the setting parameter.
