2.6 Rear Panel Introduction

Different models of IT6500C Series power supply have different rear panels. 4U
models have same rear panels as 2U Model except system bus and AC input
terminal. The cabinets have same rear panels. The rear panels are shown as
below.
No.
1
2
3
4
5
6
7
8
9
10
Function
Description
Serial request query
Power supply in CP
mode
Name
GPIB interface
RS232 interface
LAN interface
USB interface
Fan
Ground screw
AC power input
socket and cover
The positive termi-
nal of output
Sense terminals
The negative ter-
minal of output
Copyright © Itech Electronic Co., Ltd.
Flag Function Description
Prot Protections occur
Trig Power supply in triggering
state
Description
GPIB connector interface. Can be selected to use
from front panel menu.
Only for IT6500C(G) series.
RS232 connector interface. Can be selected to
use from front panel menu.
LAN connector interface. Can be selected to use
from front panel menu.
USB connector interface. Can be selected to use
from front panel menu.
Fan for cooling the device.
Ground screw for making chassis ground
connections
Used to connect AC power to start instrument
The positive terminal of output for connecting
DUT.
Remote sense terminals, used for maximizing
measurement accuracy
The negative terminal of output for connecting
DUT
