3.13 Setting Maximum and Minimum Values

The maximum voltage of the power supply ranges from V-min to full-rated
output voltage. Press the composite key [Shift] + [V-set] (Setup) to enter the
Configuring Menu for setting maximum and minimum values of power supply
voltage, current and power , maximum and minimum values of load current and
power. When limit setting is finished, the voltage, current and power setting
values can only be set within the maximum and minimum limits.
Set the maximum and minimum voltages as follows:
1. Press the composite key [Shift]+[V-set](Setup) to enter the Configuring
2. Select Source in the menu and press [Enter] for confirmation.
3. Select Limit with Left/Right key and press [Enter] for confirmation.
4. Set the V-Max with numeric key and press [Enter].
5. Set the V-Min with numeric key and press [Enter] for confirmation.
6. Set maximum/minimum current or power with numeric key or press [Esc] to
Function and external analog programming are not limited by Limit.
Menu.
Or, the user can select "Load" to set the load Limit. For load, you can only
set the maximum and minimum limits of the current and power.
Or, select the maximum/minimum current or power with Arrow key.
exit menu setting.
After the maximum/minimum voltage is set, the output voltage can only be
set within this range. Vmax factory setting is the rated output voltage of
corresponding model of the power supply. V-Min is 0V.
