3.2 Setting Current

The constant current range is from 0A to the maximum current value. It is very
easy for you to set the constant current output. When you press [I-Set], this
button will be lit, and you can set the constant current value. You have 3
solutions to set the constant current value.
•
•
•

3.3 Setting Power

The constant current range is from 0W to the maximum power value. It is very
easy for you to set the constant power output. When you press [P-set], this
button will be lit. Then you can input the power value by numeric and press
[Enter] or [OK] button to confirm.

3.4 Output On/Off Button

[On/Off] button is used to control the output state of power supply. If [On/Off]
button is lit, this represents output is open. And in on mode, the indicator lamp
(CC/CV/CW) will be lit.
[Fine] button (fine adjustment, change the value in decimal bit), move the
cursor by left and right keys, then to adjust values through ▲and▼.
Directly input through number keys. Input the value you want to set and then
please press [Enter] or [OK] button to confirm.
Using knob to set value, Press [I-set]button, press [Coarse] button (coarse
adjustment, change the value in integer bit) or [Fine] button (fine
adjustment, change the value in decimal bit), and then rotate the knob to set
the value.
Using left and right direction key to set value. Press [I-set]button, press
[Coarse] button (coarse adjustment, change the value in integer bit) or
[Fine] button (fine adjustment, change the value in decimal bit), move the
cursor by left and right keys, then to adjust values through ▲and▼.
Please ensure that the DC source and product under test have been
connected well before you press[On/Off] button.
