7. Select the Wave arranged and count of repetitions in sequence. The Wave
8. Select Save to File = 01 to save. Press [Esc] not to save and return back to
Run List File
After editing List file, the user needs to set the trigger mode and run List
function. Return to the main screen for triggering. Detailed steps are as follows:
•
•
2nd Wave Select = 02
2nd Wave Repeat = 1
count and arrangement sequence of each List file can be defined by the
customer based on requirements. A List file can link 10 Waves at most. The
edited Wave count shall be consistent with the one defined by the customer.
the List Setting screen.
Before starting up List function, please set trigger mode first. See Section
3.9.3 Trigger Mode .
Trigger the List file as follows
1. Press [Shift]+ [I-set](Function) to enter List operation.
2. Press the Right key to select Recall from the menu, and press [Enter] for
confirmation.
Recall File Name = 01
3. Press Arrow key to select Off, and press [Enter] for confirmation. Then,
Off is changed to On. List function is switched on.
On Recall EditFile EditWave
4. Press [Esc] back to the main screen. Press [On/Off] to switch on power
output. The screen is displayed as follows.
0.00V 0.00A
0.0W List
5. Press [Shift]+[Enter](Trigger) for triggering. The VFD Trig is lighted up.
If On Recall EditFile EditWave is displayed under LIST MENU or the
external analog control function is switched on, neither List nor Wave file
editing is accessible. In this case, change On Recall EditFile EditWave
to Off Recall EditFile EditWave before operation.
