Adjust the voltage or current set value
The voltage knob or the current knob is used to adjust the voltage set value or
current set value. Rotate the knob clockwise to increase the set value and
anticlockwise to decrease the set value.
•
•
Select the menu item
The voltage adjustment knob can be used to select the menu item. Press
[Shift]+ [P-set](Menu) to enter the menu interface and then rotate the voltage
adjustment knob to select the menu item from left to right.

2.5 VFD Indicator Lamps Description

IT6500C series power supply VFD indicator lamps description as follows:
Table 2–2 Function VFD indicator lamps description
Flag
OFF
CV
CC
*
Rear
Shift
The user can press the [Coarse] button and then rotate the knob to adjust
the set value in integer bit. The step size of Coarse adjustment is 10. You
can press left and right navigation key to move the cursor position.
The user can press the [Fine] button and then rotate the knob to adjust the
set value in decimal bit. The step size of Fine adjustment is 0.1. You can
press left and right navigation key to move the cursor position.
Function
Description
Power supply in off
mode
Power supply in CV
mode
Power supply in CC
mode
Open the keylock
function
"Meter" button in on
mode
using composite
function
Copyright © Itech Electronic Co., Ltd.
Flag Function Description
CR None
Sense None
Auto None
Addr When received command
successfully, the flag will
display 3 seconds.
Rmt Remote control mode
Error Error occur
Quick Reference
