The functions of the posh-on knob is described as follows.
•
•
•
Adjust the Value Setting
In the value setting interface, rotate the knob clockwise to increase the set value
and anticlockwise to decrease the set value.
Select Menu Item
The knob can also be used to view menu items. In the menu item display inter-
face, turning the knob clockwise indicates that the next menu item is selected,
and turning the knob anticlockwise indicates that the previous menu item is
selected.
Confirm settings
After completing the value setting or selecting a menu item, pushing the knob
acts like pressing [Enter] key to confirm the operation.

1.5 Rear Panel Introduction

The rear panel of the of the this series model (after removing the protective cov-
er) is shown below.
1U Models
2U Models
Adjust the value setting
Select menu item
Confirm the set value or the selected menu item
