11. AC power input terminals (L1, L2, L3, and PE)
12. Chassis ground terminal

1.6 VFD Indicator Lamps Description

The IT6000C series Bi-directional Programmable DC Power Supply VFD indica-
tor lamps description is as follows:
Table 1–1 VFD Indicator Lamps Description
Flag
OFF
CV
CC
*
CR
Shift
SRQ
CW
Function
Description
The output of the
power supply is
turned off.
The power supply is
in a state of con-
stant voltage
output.
The power supply is
in a state of con-
stant current output.
The keyboard lock
is turned on.
The power supply
(Sink) is in constant
resistance state.
Using composite
function key
Indicates that the
internal status re-
quest event occurs.
The power supply is
in a state of con-
stant power output.
Copyright © Itech Electronic Co., Ltd.
Flag Function Description
Sense Sense function of the power
supply is enabled.
Rear Analog function begin to
work.
Addr When received command
successfully, the flag will dis-
play 3 seconds.
Rmt Indicates that the instrument
is working in remote control
mode.
Error Error occur
Prot The instrument enters the
protection state.
Trig The instrument is in a state
of waiting for a trigger.
- -
