Appendix C: Signal Connection of MCU DI/DO

a C: s
PPendIx

GPIO Pinout Description

1 5
1 5
1 1 1 5
11 15
Pin Definition
1 GPI 1
3 GPI 3
5 GPO 1
7 GPO 3
9 VIN-GPIO
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
C
IGnal onneCtIon of
Pin Definition
2 GPI 2
4 GPI 4
6 GPO 2
8 GPO 4
10 GND
mCu dI/do

GPO Pull High Selection (JP5)

2 12
1 11
Pin
1-3 Short GPO1 Pull High (Default) Voltage by Vin
3-5 Short
9-7 Short GPO2 Pull High (Default) Voltage by Vin
9-11 Short
4-2 Short GPO3 Pull High (Default) Voltage by Vin
4-6 Short
10-8 Short GPO4 Pull High (Default) Voltage by Vin
10-12 Short
60
Definition
GPO1 Float
GPO2 Float
GPO3 Float
GPO4 Float
