Appendix E: Pin Definition for the Multi Port Cable
CN1 Connector Pinout
8
2
1
3
7
6
4
5
Pin
Definition
1
D-
3
VCC
5
D1
7
VCC
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
D+
4
GND
6
D+
8
GND
CN2 and CN3 Connector Pinouts
USB Connector
Connector location: CN2
1
4
CN1 Pin CN2 Pin
1
2
2
3
3
1
4
4
74
Definition
D-
D+
VCC
GND
VTC 6222 and nROK 6222 User Manual
