Chapter 3: Jumpers and Connectors

Jumper and DIP Switch Settings

GPO Pull High Selection

Connector type: 2x6 12-pin header, 2.0mm pitch
Connector location: JP5
2 12
1 11
Pin
1-3 Short GPO1 Pull High (Default) Voltage by Vin
3-5 Short
9-7 Short GPO2 Pull High (Default) Voltage by Vin
9-11 Short
4-2 Short GPO3 Pull High (Default) Voltage by Vin
4-6 Short
10-8 Short GPO4 Pull High (Default) Voltage by Vin
10-12 Short
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Definition
GPO1 Float
GPO2 Float
GPO3 Float
GPO4 Float

GPI Pull High Selection

Connector type: 2x6 12-pin header, 2.0mm pitch
Connector location: JP6
2 12
1 11
Pin
1-3 Short GPI1 Activity Low (Default) Voltage by Vin
3-5 Short
7-9 Short GPI2 Activity Low (Default) Voltage by Vin
9-11 Short
2-4 Short GPI3 Activity Low (Default) Voltage by Vin
4-6 Short
8-10 Short GPI4 Activity Low (Default) Voltage by Vin
10-12 Short
28
Definition
GPI1 Activity High
GPI2 Activity High
GPI3 Activity High
GPI4 Activity High
