Chapter 3: Jumpers and Connectors

Half Size Mini-PCIe Socket (USB 2.0, PCIe 2.0)

Connector location: CN10
1 2
51 52
Pin Definition
1 PCIE_WAKE#2
3 N.C
5 N.C
7 PCIE_CLKREQ2#
9 GND
11 PCIE_CLKN2
13 PCIE_CLKP2
15 GND
17 N.C
19 N.C
21 GND
23 PCIE_RXN2
25 PCIE_RXP2
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 +V3.3_MINI_2
4 GND
6 +V1.5S_MINI_2
8 NC
10 NC
12 NC
14 NC
16 NC
18 GND
20 WIFI_DIS#_B
22 PCIE_RST#
24 +V3.3_MINI_2
26 GND
Pin Definition
27 GND
29 GND
31 PCIE_TXN2
33 PCIE_TXP2
35 GND
37 GND
39 +V3.3_MINI_2
41 +V3.3_MINI_2
43 GND
45 NC
47 NC
49 NC
51 BT_DIS#_B
40
Pin Definition
28 +V1.5S_MINI_2
30 NC
32 NC
34 GND
36 USB_4N
38 USB_4P
40 GND
42 N.C
44 WLAN_LED#_B
46 N.C
48 +V1.5S_MINI_2
50 GND
52 +V3.3_MINI_2
