Appendix E: Pin Definition for the Multi Port Cable
The multi port consists of a 15-pin male D-sub connector and multiple output
connectors. The following tables in this appendix list the pin signals of the
P1 connector and its corresponding pin signals to the output connectors.
nROK 6222 Rear View
VTC 6222 Rear View
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Multi Port Cable
P1
76
P2
P3
P4
P5
VTC 6222 and nROK 6222 User Manual
