Appendix F: Power Consumption
a f: P
PPendIx ower
OS: Windows 10
Burn-in Software:
Device:
Idle: Into OS + display x 3 + all module (unlink) + keyboard & mouse + audio
Full State: Burn-in 100% + mini PCIe dummy load + play video + keyboard & mouse + audio + COM trans + GPS link
Full State + Loading: Full state + USB load (5V/1A x 1, 5V/0.5A x 3) + DC out (12V/2A) + PoE dummy load (15W x 4)
Item Device
1 S0 State
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
C
onsumPtIon
Test Case
Idle State
(Display x 2 <VGA + HDMI>)
Full State
Full State + Loading
Full State + Loading
(+PoE x 4)
Result
Current(A) Watt(W)
12V 1.85
24V 0.94
36V 0.71
48V 0.56
12V 2.91
24V 1.49
36V 1.06
48V 0.82
12V 6.28
24V 3.13
36V 2.15
48V 1.63
12V 12.76
24V 6.21
36V 4.2
48V 3.18
82
22.2
22.56
25.56
25.92
34.92
35.76
38.16
39.36
75.36
75.12
77.4
78.24
153.12
149.04
151.2
152.64
