Appendix E: Pin Definition for the Multi Port Cable
The DIO port consists of a 15-pin female D-sub connector and multiple output
connectors. The following tables in this appendix list the pin signals of the
P1 connector and its corresponding pin signals to the output connectors.
DIO Port Cable
nROK 6222 Rear View
P1
VTC 6222 Rear View
80
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
VTC 6222 and nROK 6222 User Manual
