USB Connector
USB connector is a sealed receptacle, 5 pin, ODU p/n G80F2C-P05QF00-0000 (Figure 3).
Table 8 gives the USB connector specifications.
www.javad.com
Table 7. RS-232C Cable Connector Specifications
Number
Signal Name
1
Power_OUT
2
GND
3
CTS
4
RTS
5
RXD
6
TXD
7
Figure 3. USB Connector
Table 8. USB Connector Specifications
Number
Signal Name
1
USB ID
2
USB_PWR
3
GND
4
USB D+
5
USB D-
Dir
P
Power Output (supplied voltage)
-
Signal ground
I
Clear to send
O
Request to send
I
Receive data
O
Transmit data
Not used
2
3
1
4
5
Dir
I
USB ID
P
Bus power
-
Ground
I/O
Data plus
I/O
Data minus
