• In applications where real-time positioning results are required, the Base receiver provides the
correction information needed to properly calculate the location of the Rover receiver. A Base
station is normally set up over a known point and collects GPS/GLONASS data from satellites.
As the receiver picks up satellite data, it measures the carrier and code phases to accurately
compute and verify its location. Then, the receiver transmits this information via radio (UHF or
GSM) to the Rover receiver.
• The Rover receiver applies correction information from the Base station to its current location to
accurately calculate one or more points. Rovers are mobile GNSS receivers on a survey pole or
bipod that compares the information from the Base station to the data it logs from satellites and
applies correction algorithms to accurately calculate a new point.
In applications intended for post-processing, the receivers typically log code phase and/or carrier phase
measurements separately from common satellites and during the same time interval. This data is then
processed using post-processing software (for example, Justin).
The following Base and Rover configurations are recommended for the most common applications.
However, you can select configuration parameters as needed for your particular jobsite.
Note:
Do not make other changes without consulting the NetView Software Manual.
1. Connect the receiver and computer, start NetView and establish the connection as described in
"Connecting the Receiver and a Computer" on page 28.
2. Click ReceiverParameters on the left panel.
Note:
Click Apply every time after the parameter was changed, otherwise the receiver won't save the changes.
Click Refresh, to ensure the changed parameters and new configuration are saved.
3. In the General tab check antenna status and set the parameter Antenna Input to External if the
external antenna will be used (Figure 26 on page 42).
