Description and Operation
Configuration
Configuring the Internal UHF Modem / GSM Module
3. In the Service tab Main subtab specify the following parameters (Table 6) and click Apply
(Figure 23 on page 39).
Parameter
Mode
TCPCL port
38
Figure 22. GPRS tab
Table 6. Receiver Parameters for the Service Tab Main Subtab
•OFF means service is disabled.
•RCV means that modem will receive data from another (remote) JAVAD GNSS
receiver configured as a base station. This base station have to be connected with
Internet via Ethernet or GPRS and have static IP address.
•NTRIP are useful to provide a method to establish connection to an NTRIP caster,
request data from particular mount point, and then receive and use the data as RTK/
DGPS corrections.
•SERVER - this mode allows working with JAVAD server.
Specify the type of incoming data to accept on the TCPCL receiver port:
•None means that the port will ignore any incoming data.
•Command - port is in command mode. Being in this mode, the receiver's port
recognizes commands sent by the user.
•Echo - echo mode.
•RTCM 2.x - RTCM 2.x input mode.
•RTCM 3.x - RTCM 3.x input mode.
•CMR - CMR/CMR+ input mode. For more information on CMR format, please refer
to ftp://ftp.trimble.com/pub/survey/cmr.
•JPS - JPS input mode. In this mode receiver is capable to recognize both standard and
non-standard JPS messages.
Value
